ZPW29 Large Tablet Press

ZPW29 Large Tablet Press is a double-press type.continous automatic tablet press for pressing granular raw materials into tablet - details see: https://www.machineto.com/zpw29-large-tablet-press-10309174

Condition:New	Place of Origin:Jiangsu China (Mainland)	Brand Name:NOAH	Model Number:ZPW29
Type:Rotary Tablet Press,Tablet Pressing Machine	Production Capacity:99.9%,125000 pc/h	Dimension(LWH):12309501700mm	Certification:GMP, CE
Product Name:Large Tablet Press	Standard:GMP,CE	Material:Staninless Steel	Application:Tablet
Model:ZPW29	Turret Speed:14-36 r/min	Motor:4kw 1440 r/min 380/50 V/Hz	Net Weight:1880kg

Our ZPW29 Large Tablet Press is a double-press type.continous automatic tablet press for pressing granular raw materials into tablets.It is mainly used in pharmaceutical industry and also the chemical,food,electronic industries.

Characteristics:

1.Produce all kinds of round tablets,irredgular tablets,double-layered and annular tablets.

2.The outside part of the machine is fully-enclosed,The material of the cover and the inside bable face is stainless steel.The turret face is specially disposed keeping the lustre of the face and prevent the cross pollution,meeting the GMP requirement.

3.It has transparent windows so that press condition can be observed clearly and the window can be opened Cleaning and maintenance is easier.

4.The lay-out of all the controllers and the operate parts is reasonable.

5.The speed adjustment of the driver is controlled by the frequency conversion device.

6.All the drive devices are located inside the machine so keep the machine clean.

7.A overload protection unit is included in the system to avoid the damage of the punches and apparatus,when overload occurs,the machine stops automatically.

8.The punches and dies are also applicable to Model ZP19 ZP33.

Main technical Data:

ITEM	TYPE
ITEM	ZPW29	ZPW31
Dies	29sets	31sets
Max. Pressure	100KN	100KN
Max. Dia of Tablet	13mm(18-22)	13mm(18-20)
Max. Depth of Fill	15mm	15mm
Max. Thickness of Tablet	6mm	6mm
Turret Speed	14-36 r/min
Production Capacity	125000 pc/h	135000 pc/h
Motor	4kw 1440 r/min 380/50 V/Hz
Overall Size	12309501700mm
Net Weight	1880kg

Nouya Machinery Companyis one famous group and apply itself to R&D,manufacture machinery for Pharmaceutical,Chenical,food and so etc fields.

OurMain Productsare: Tablet press,Mixer,Crusher,Granulator,Dryer,Coater,Packing machine,Filling Machine,Miller and Pulverizer, Feeder,Oven, Deduster, Dust Collector, vibration sieves...

We also supply punch die sets and spare parts in standard or not.

The Headquarter is located in The beautiful,historical and culturalCity-Yangzhou.

Our production,examinaton and supervision are strictly following theISO9001 International Quality SystemandmeettheCE Certification.
