ZL30 wheel loader

Rated load:3 tons, Bucket capacity:1.7or 2 cbm, Engine: Weichai Deutz, Gearbox: Xiamen Yitong gearbox or Hangchi gearbox - details see: https://www.machineto.com/zl30-wheel-loader-10107891

Condition:New	Brand Name:RLS	Model Number:ZL30 / RG935C	Place of Origin:Fujian China (Mainland)
Type:Mini Loader	Moving Type:Wheel Loader	Dimension(Long * Breadth * High):710022503170	Rated Load:3 tons
Warranty:One year/2000 hours after date of Bill of Lading	After-sales Service Provided:Engineers available to service machinery overseas	Engine rated power:92kW	Rated Bucket capacity:1.7m3(2.0m3 as optional)
Engine Brand:Weichai Deutz/ Cummins	Operating weight:10 tons	Gearbos Brand:Xiamen Yitong gearbox or Hangchi gearbox

Specifications:

	Overall dimension
	Length(with bucket on ground)	mm	7100
	Width(to outside of wheels)	mm	2250
	Bucket width	mm	2510
	Height(To the top of the cab)	mm	3170
	Wheel base	mm	2750
	Tread	mm	1800
	Min. ground clearance	mm	370
	Main technical specification
	Rated load	kg	3000
	Operating weight	kg	≤10000
	Rated bucket capacity	m³	1.7m³(2.0m³as optional)
	Max. breakout force	KN	98±5
	Max. dump clearance	mm	3350±15
	Dump reach	mm	1050
	Max. climbing gradient	°	30
	Turning angle	°	35±1
	Dump angle at any position	°	45
	Turning radius	mm	5610
	Lifting time of bucket	s	≤5.3
	Total cycling time	s	≤9.2
	Travel speed
	1st gear forward	km/h	8
	2nd gear forward	km/h	13.5
	3rd gear forward	km/h	25
	4th gear forward	km/h	36
	1st gear reverse	km/h	9.5
	2nd gear reverse	km/h	30
	Diesel Engine
	Model		Deutz TD226B-6G
	Type		In-line, water cooled, direct injection, Turbocharger,4-stroke
	Rated power	KW	92
	Inter-bore of cylinder/stroke	mm	6-Φ108×125
	Rated speed	rpm	2200
	Max. Torque	N.M	463
	Min. specific fuel consumption	g/kw.h	230
	Torque converter
	Model		YJ315X
	Type		Single-stage three-element
	Torque coefficient		KO=2.89
	Cooling method		Oil-cooled pressure-circulated
	Oil inlet pressure	MPa	0.4-0.5
	Gear box
	Model		BS428(hangzhou)
	Type		Fixed shaft, power shift
	Gear numbers:		Forward4 Reverse 2
	Gear ratio
	Forward I		3.82
	Forward II		2.08
	Forward III		1.09
	Forward IV		0.59
	Reverse I		3.05
	Reverse II		0.87
	Transmission pump
	Rotating speed	rpm	2200
	Flux	L/min	140
	Working pressure	MPa	1.08~1.47
	Axle and tyre
	Type of main reducer		One-stage spiral bevel gear deceleration
	Gear ratio of main reducer		5.285:1
	Type of final reducer		One-stage planet gear deceleration
	Gear ratio of final reducer		3.88:1
	Tyre 17.5-25-16PPR		17.5-25-16PPR
	Working Hydraulic System
	Model of oil pump		CBGq2100
	System pressure	MPa	16
	Distribution valve model		DF25.2C
	Dimension of lifting cylinder	mm	2-ø110×780
	Dimension of tilting cylinder	mm	1-ø160×490
	Steering system
	Type		Articulated fully hydraulic steering
	Model of steering pum		CBN-E500
	System pressure	MPa	9.8
	Dimension of steering cylinder	mm	2-Φ80×294mm
	Brake system
	Type of traveling brake		Air-pushing-oil disc brake on four wheels
	Type of parking brake		Cable-controlled caliper disc brake
	Electrical system
	System voltage		24V
	battery model		6Q-180

Optional equipment

	1. Loose material bucket,rock bucket;
	2. Air conditioning system-cool wind type ,warm -wind type, cool&warm type;
	3. Various implements log,loader,side-dump loader.
	4. Quick hitch
	5. Cummins engine 6BT5.9 -C130
	6. Joystick controll
