(2).Operation is simple and stable; its control is simple and convenient, (3).Widely used in chemicals, pharmaceuticals, food. - details see: https://www.machineto.com/ypg-foodstuff-pressure-spray-drier-liquid-to-powder-dryer-10295823

Descriptions
The liquid or paste raw material is spraied into minuty liquid drop by pressed spraier draw assistance from pressure of isoulatepump, and quickly drying through amplly heat exchange.(10~90sec.) at last, the powder or small granule is finished.

Features

The dry speed is fast and suitable for drying thermal sensitivity material particularly.
The finished product is ball granile with uniform size. Its fluidity and solubility are good. The purity of product is high and its quaity is good.
It applied scope is wide. According to the characteristics of raw material,it can use hot air to dry and can also use cool air to granulate. It has strong adaptability to raw materials.
Its operation is simple and stable and its control is simple and convenient and is easy to realize automatic operation.

Applications
It is suitable for liquid of foodstuff,pharmaceutical,chemical industry,dyestuff,ceramics,agrochemicals,plastic and so on.

Model	50	100	150	200	300	500	1000
Evaporated amount Kg/h	50	100	150	200	300	500	1000
Overall dimension (Φ×H)mm	1600×8900	2000×11500	2400×13500	2800×14800	3200×15400	3800×18800	4600×22500
High pressure pump Mpa	2-10
Power KW	8.5	14	22	24	30	82	30
Air inlet temperature °C	300-350
Moisture content of product %	less than 5 can reach 0.5
Product recovery%	more than 97
Electricity heating KW	75	120	150	When the temperature below200°C,calculate on the practical conditions.
Electricity + steam Mpa+KW	0.5+54	0.6+90	0.6+108
Hot air furnace Kcal/h	100000	150000	200000	300000	400000	500000	1200000
