YAG metal laser machine GWK1530 1500*3000mm

1 on metal cutting, 2 YAG metal laser machine, 3 cnc laser, 4 auto adjuster - details see: https://www.machineto.com/yag-metal-laser-machine-gwk1530-1500-3000mm-10354775

Condition:New	CNC or Not:CNC	Place of Origin:Shandong China (Mainland)	Brand Name:g.weike
Model Number:GWK1530	Certification:CE	Warranty:one year	After-sales Service Provided:Engineers available to service machinery overseas
METAL:BIG

YAG metal laser machine GWK1530 1500*3000mm

contact supplier for YAG metal laser machine GWK1530 1500*3000mm

GWK1530 YAG metal laser machine

Compare to CNC router, GWK laser cutting machine have following advantage

1. Can process various complex structures, any image drawing by computer, can be processed by this machine.

2. No need to open mode. Only need design the file from computer, then the product can come out immediately. Can quickly develop new products, and save the cost.

3.cutting machine with automatic tracing system, is able to complete the flat cut and avariety of uneven surfaces cut.

4.Those complex technical requirements can not completed by the CNC machine, this YAG laser cutting machine can do it well.

5.Can produce the products with smooth surface in high grade. But CNC machine is hard to achieve.

6. Molding body (less than 0.5 m thick) need the hole trench processing. CNC machine can not handle it, but YAG laser cutting machine is workable.

This model adopts DSP controlling system, auto height adjust system imported from USA, linear guide and ball screw imported from Taiwan, servo motor imported from Japan, USA lens and mirrors, special double ball screw and double servo transmitting system on Y axis, strong structure for whole machine. All these characters made this machine to get the leading level for both function and stability.

Specification

Model number:GWK1530

working area:3,000mm×1,500mm

machine size:4,340×2,430×1,350mm

Max. cutting thickness:6mm(carbon steel)

Max. output power:620W

laser wavelength:1064nm

Pulse Frequency:1-300HZ

Minimum line width:0.15mm

X,Y,Z axis Resetting position accuracy:≤±0.04mm

Cooling mode:7P 7P water cooling system

Max. cutting speed:35mm/s

Voltage:380V/50HZ/100A

Whole machine Weight:3800kg

Appliable industries

Widely used in the line of advertising board, Sheetmetal structure, high and low Voltage elictric cupboard industry, spare parts of the textile machines, hardware, metal handicraft article, kitchen wares, cars, machines, elevators, spare parts of the elictric devices, spring pieces, spare parts of the subway and so on.

Appliable material

Stainless steel, carbon steel, alloy steel, spring steel, Aluminum alloy, copper plate, Aluminum plate, gold, silver, Titanium, other metal plates and metal pipes.
