Home  >  Wood Working Machinery  >  Woodworking Machinery  >  Wood Debarker

pls feel free to contact with Ms Coco 0086-18703683073, we are manufactory about the machines , - details see: https://www.machineto.com/wood-debarker-debarking-machine-wood-peeling-machine-10351342

1. company introduction :

Connect : Ms Coco

Mobile : 18703683073

Tel : 0086-371-86660712

Fax:0086-371-86660713

Skype : Taizy2025

2. details for the machine

Advantages:
1.High efficiency , low power consumption and save labour force
2.Operated easily, high productivity, little injury for the wood

This Wood Peeling Machine suitable for various kinds of tree, with feature of high output and easy operation

lt Suitable for most kinds of wood especially wood with lots of fiber .

Also suitable for : needle wood , pine trees , also eucalyptus , poplar with high moisture

1>This machine is the rotor teeth with stripping produced a unique force, so that wood in the hopper tank plate section of a recurring cycle of movement, but also around its own axis to do wood turning motion segment and irregular beating. To this paragraph with wooden teeth, wood and wood paragraph paragraph paragraph wood and keep the friction between the storage tank, impact, compression, fast bark are separated, to achieve effective peeling effect.

2>One end to put in and the other for outlet , it’s better than the rotary one which have to stop the motor to take the peeled trees out

3>Can suit for many kinds of different trees , especially for the bend one have more high peeling rate than the traditional rotary type

4>The machine is fixed when working , so the power consumption and the failure rate is small and with low noise

3. details parameters :

Model		TZ-A	TZ-B	TZ-C
Motor		11kw /22HP Diesel	15kw / 38 Diesel	22kw / 55 HP Diesel
Capacity		8-9t/h	10-12t/h	12-15t/h
Debarking rate		>95%	>95%	>95%
Suitable length of wood		6m	8.3 m	9m
Suitable wood diameter		20-500mm	20-600mm	20-700mm
Machine weight		3.8T	5.2 T	6.5T
Machine size		8000*1400*1700mm	9300*1400*1700mm	11*1.6*2m
Worker needed		1-2 persons	1-2 persons	1-2 persons
Belt size	Length	16m	18m	22m
	Width	600mm	600mm	600mm

4. machine pictures :

5. connect details :
