Raymond Mill, Easy maintenance, High efficiency--mill, Good performance--raymond mill, low cost - details see: https://www.machineto.com/who-can-tell-me-something-about-gypsum-powder-making-plant-10314775

Gypsum powder making plant is an traditional and efficient tool for fine powder grinding. It is used to grind many kinds of minerals. Gypsum powder making plant is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.
To use the Gypsum powder making plant, the material to be ground is loaded into the Neoprene barrel that contains grinding media. As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours. Obviously, the longer the Gypsum powder making plant runs, the smaller the powder will be. Ultimate particle size depends entirely on how hard the ground material is, and how long the Gypsum powder making plant runs. Our Gypsum powder making plant have been being used to grind glass, make ceramic glaze, powder various chemicals, and make Black Powder.
Gypsum powder production line
Gypsum powder production lineis the natural gypsum calcining heat after a certain temperature, the decomposition of gypsum dehydration, the resulting half-water gypsum as the main ingredients, namely, gypsum. Decomposition under the dehydration temperature and pressure used in different conditions.
The typical gypsum processeing plant
Mechanized production of gypsum, the basic technical processes: Milling system, automatic metering system, calcining system, heating system and aging packaging systems and other systems, the following brief description of each system.
Gypsum mining
Gypsum mining, drilling rig equipped with large, shovel loading equipment and transport vehicles, using Taiwan-stage, in the deep hole blasting, etc., so that zero discharge of waste production, protect the environment, and full use of the gypsum resources.
Gypsum raw materials crushing system
Gypsum raw materials through the automatic feeder into the Jaw crusher,Jaw crusher is widely applied to Gypsum crushing process. It crush large-size gypsum ore broken into small particles less than 25mm, and set aside. The production process is simple, reliable, advanced, energy-saving. And can be equipped with dust removal equipment, protecting the environment clean, to meet environmental emissions requirements.
Gypsum raw materials feeding and screening
Gypsum raw materials delivered to students through the elevator hopper aside.Gypsum powder production processin accordance with the requirements of advanced metering system for accurate measurement, the raw material into the mill. Storage silo storage root show the time required for material design specifications, to ensure stable supply of materials.
Gypsum Grinding System
After measuring the raw materials into the mill for finishing. Fluidized electromagnetic vibrating feeder is set, the equipment and the mill chain, according to the operation of real-time adjustment of the mill material supply. Material by belt conveyor into themillcontinuously and evenly, for grinding. After the material grinding system by the size of 0 ~ 30mm, 80 ~ 120 mesh change, in line with gypsum powder fineness requirements.
JOYAL Gypsum powder production line Features:
a.Easy and safe operation
b.Stable performance
c.Even product size
d.Low energy consumption
e.Low invest, high return

Technique data of Joyal High Efficient Raymond Mill

Model	Grinding Roller			Grinding Ring		Feeding Size (mm)	Output Size (mm)	Capacity (t/h)	Motor Power (kw)	Overall Dimension (mm)
	Numbers (pcs)	Diameter (mm)	Height (mm)	Outside Diameter (mm)	Height (mm)
3R2115	3	210	150	726	150	<15	0.613-0.044	0.28-1.8	28.2	4480× 3100× 3970
3R2615	3	260	150	865	150	<15	0.613-0.044	0.35-2.8	35.7	5000× 4100× 4850
3R2715	3	270	150	884	150	<15	0.613-0.044	0.40-3.4	42.7	5050× 4150× 4900
3R3015	3	300	150	965	150	<15	0.613-0.044	0.45-3.7	55	5200× 4200× 4950
4R3016	4	300	160	990	160	<20	0.613-0.044	0.6-4.5	55	5250× 5000× 5500
4R3216	4	320	160	1073	160	<25	0.613-0.044	1.0-5.2	72.5	7700× 7200× 8800
