Tunnel construction equipment

1.Concrete spraying machine, 2.20 years experiences, 3.Exported to India, 4.6m3/h,2100X900X1200mm,1500kg, 5.Inner size:2'',2.5'' - details see: https://www.machineto.com/tunnel-construction-equipment-10096568
Condition:NewMax. Conveying Distance:200mMax Aggregate Size:20mmHose Inner Diameter:51 mm
Air Consumption:10m3/minPlace of Origin:Henan China (Mainland)Brand Name:XudaModel Number:PZS-2
Voltage:380VPower(W):7.5KWDimension(L*W*H):2100X900X1200mmWeight:1500kg
Warranty:1 year,1 year for motor,reducerAfter-sales Service Provided:Engineers available to service machinery overseasColor:CustomizedSpare parts:Sealing plate,Hose,etc
Application:Construction,Tunnel,coal mineDriven:Motor,Diesel engineMax transffering distance:35mMaterial:<15mm,liquidity
Inner size of hose:51/64mmRebound rate:<10%Accelerator slump:8-15cm
Tunnel construction equipment
contact supplier for Tunnel construction equipment


Zhengzhou Wet mix concrete spraying machine

Applications:

1. Concrete machine for tunnels,hydro-power engineering,mines,underground engineering,

civil engineering and slope stabilization,etc.

2. Atificial soil seeding for no soil surface, such as rock, sand, and for no fertility

soil surface.

3. Refractory material spraying and repairfor industrial kilns or kilns’s inner liner.

Features:

1. Advantages:XuDa PZS-2 is a new & high-efficient concrete-spraying machine,

mainly used forwet-mix shotcreting. It has the advantages of simple cooperation,

low dust consisitency, low rebound, high-strength of concrete layer, saving material

and protecting environment.

2. This machine is suitable eitherfor manual spraying orby means of a rototic arm.

Technical Data:

ItemItem
Output5~6m3/hConcrete slump8-15cm
Max.convay dist.35mDischarge height1.2m
Main electric motor modelY132M-6Main electric motor power7.5kw
Max. aggregate size15mmDosing pump output17.5~88L/h
Operating air pressure0.3~0.6MpaDosing pump rated pressure0.6Mpa
Air consumption10~12m3/minOverall dimension2100×900×1200
Hose inner size51/64mmweight1500kg

Drawing

1.Rotor body assembly 2.Compression structure 3.Limit Block 4.Cyclone 5. Hopper

6. Vibration Motor 7. Main Motor 8. Housing 9. Hand wheel speed 10. Speed display

11. Transmission 12. Pressure Gauge 13. Add quick setting agent pump

14. Electronic Control Box 15. Steering 16. The total inlet tube 17. Sub-style device 18. Upwind Road

19. Leeward Road 20. Reducer

Principle

Consumable parts

Details picture

Glance in factory

Packing picture

Tunnel construction equipment
Packaging Detail:Stanard fumigation wooden box or customizedThickness of lower board is 30cm
Delivery Detail:Within 5 working days
