1.bi-direction bending.double wire production capacity, 2.import bands for main parts, stirrup bending machine,steel wire bender - details see: https://www.machineto.com/stirrup-bending-machine-for-5-12mm-10123826

Automatic stirrup bending machine, controlled byCNC, quickly and automatically measure, straighten, bend and cut, instead of20~30workers.

Stirrup bending machinetypes:

WG16A/WG16B/WG12B-2/WG-12E/WG-12D /WG8-25E

Material feeding system:

2 payoffs with brakes, suitable for single and double strand, buffer unit can reduce the resistance and instability .

Straightening system:

one horizontal straightening unit and one vertical straightening unit (patented technology) combine with 4 traction rolls drove by servo motor, this ensures wires can reach the most accurate straightening effect

Bending and cutting system(patented technology):

bending arm driven by servo motor can protrude or draw back while bending different angles, it will finish cutting work synchronously.

Control system:

CNCcontrol with malfunction alarm,PLC,servo motorand electric components useJapan and Germany brand

edit any 2D shapes with max.50angles, the data base can store more than 500 shapes.Different shapes can be processed continuously without stop

Model	WG-12B-2	WG- 16B
Single wire	Φ6 – 12 [mm]	Φ6 – 16 [mm]
Double wire	Φ6 – 10 [mm]	Φ6 – 10 [mm]
Max bending angle	180°	180°
Max bending speed	800 – 1050 [°/sec]	800 – 1050 [°/sec]
Max pulling speed	90 – 110 [m/min]	90 – 110 [m/min]
Max length of the stirrup side	1300 [mm]	1300 [mm]
Min length of the stirrup side	60 – 90 [mm]	60 – 90 [mm]
Length tolerance	± 1 [mm]	± 1 [mm]
Bending tolerance	± 1°	± 1°
Production capacity (single wire)	900 [pcs/h]	900 [pcs/h]
Production capacity (double wire)	1800 [pcs/h]	1800 [pcs/h]
Average air consumption	6 [l/min]	6 [l/min]
Average power consumption	5 [KW]	10 [KW]
Installed power	30 [KW]	50 [KW]
Bending direction	Double direction	Double direction
