1.stainless steel constructure, 2.Can produce wrapper in different shapes /thickness/ size ., 3.Used for dumpling /wonton etc . - details see: https://www.machineto.com/stainless-stee-automatic-delicious-spring-roll-making-machine-0086-13782789572-10041316

Your satisfaction is our mission !

1.construction and working principle

1)the main part is shaft to deliver dough,filling and other ingredient .

2)At work ,put the dough into dough bucket then the screw propeller will put the dough into exit to form macaroni tube .At the same time ,the filling will be pushed by double-stage pump into macaroni tube ,after through forming mould becoming dumpling .

2.features

1)the thickness of wrapper and the quantity of filling can be adjusted .

2)The dumpling has beautiful appearance .

3)By changing machine head ,it can produce spring roll ,wonton ,wonton dumpling ,steamed dumpling ,samosa ,lace dumpling and fried dumpling etc .

4)the weight and shape can accord to customers’ requirements .

3.advantages

1)Power adopt gear and chain type

2)Dry flour rolling and surface, and uniform flour!

3)non-stick surface materials production, is more smoother!

4)Stuffing dumplings dragon the spiral can make all kinds of meat, meat dishes, mix filling, whole turnip and other kinds of filling of dumplings!

5)Molding part adopts the technology of the anti caking, small resistance forming good easy cleaning can be customized according to customer's require!

6)adopting national motor ,it’s more safe to use .

Model	ZFH-80
Dumpling weight	8-35g
Capacity	4000-4800 pcs/h
Motor	2.2kw/1.5kw 2/3 phrase power
Machine weight	115kg
Boundary dimension	670mmx420mmx730mm
Packing	Wooden case

Other production parameter

Item	Spring roll	Fried dumpling	Samosa	Wonton	Pearl dumpling
Weight	50-60g	25-28g	15-17g	6-10g	4-10g
Size	60X32mm	90X45mm	65X65mm	65X65mm	40X20mm

Photo show

can produce different products as your requirements by change mould.

easy to operate
