1.Grinding various paint,oil printing ink, pigment,paste material, 2.Refining and polish, 3.Voltage can be custom-tailor - details see: https://www.machineto.com/soap-machine-high-quality-three-roller-grinding-machine-chemical-machine-10284676

Three roller machine used for refining and polishing

Item NO. :AMSIM0120

It have the function grinding ,dispersing,emulsifying,colormatch,makes the raw material highly homogeneously mixed in it.

minimum model mainly used for scientific reasearch,test,formula minim debugging.middle,large scale used for continuously produce.

Model	S65	S150	S260	S405
Roller diameter(mm)	65	120	260	405
Roll tube length(mm)	125	300	695	810
Rollers ratio(fast.middle.slow)	≈1,3,9	≈1,2.4,4.98	≈1,2.5,6.25	≈1,2.87,8.1
Slow roller r/min	32	25.3	19.1	12.2
Middle roller r/min	89	63.25	54.5	40
Quick roller r/min	250	152	155.3	116
Roller drum speed ratio(front.middle.after)	7.8,2.8,1	02,05.5	8.13,2.85,1	9:03:01
Moter model	YL8024	Y100-4	Y160L-6	Y180L-6
Power (kw)	0.75	2.2	7.5	15
Speed R.P.M	1400	1420	970	970
Production capacity(kg/h)	1	8	18	38
The weight (kg)	80	600	2300	5218
Shape dimension (long x width (high) mm	440×420×400	820×800×920	1645×1350×1100	1980×1848×1300

Welcome all the customers to contact us,we promise to give you best price and quality service.It is our hornor to offer service to you.
