Working Mass kg 20000, Module Mass On Front Drum kg 9600, Module Mass On Rear Drum kg 10400, Static Liner Load N/cm 450 - details see: https://www.machineto.com/single-drum-vibratory-road-roller-hot-sale-10121690

Power System
Optional power system such as Cummins or Shangchai diesel which has high torque reserve, high fuel efficiency, convenient maintenance and national environmental standard-compliant emission and noise.
Transmission Control System
In electro-hydraulic powershift transmission,comfortable handfeel, stable shifting, and labor relief.
Braking System
Caliper disc service brake and band-type parking brake are independent each other and reliable.
Radiator
Enlarged fan and radiating area, unique design for air flow and water tank ensure a normal working condition even in a extremely high temperature.
Cab
Innovative cab offers a maximum view, and is characterized by dustproof, sound and heat insulation, shock absorption and anti-ultraviolet. The operating system is designed according to human engineering principle and offers a user-friendly environment, heater is optional for cab.
Vibratory system
Enclosed system composing of imported plunger pump and motor has a reliability quality and equal compaction. Vibratory drum has a big diameter, high static linear pressure and improved structure & vibrating parameter.
Maintenance
Modern streamline engine enclosure has double access doors to ensure a convenient service and maintenance.
Quality Assurance Key electronic components are imported world brand ones.

Item	Unit	DKT227
Working Mass	kg	22000
Module Mass On Front Drum	kg	10600
Module Mass On Rear Drum	kg	11400
Static Liner Load	N/cm	492
Theoretical Gradeability	%	25
Min. Turning Radius	mm	≤6500
Vibrating Frequency	Hz	29
Norminal Amplitude@High/low	mm	2.1/1.1
Centrifugal Force@High/Low Amp	kN	340/220
Vibrating Drum Dia.	mm	1600
Vibrating Drum Width	mm	2150
Engine
Make		Shangcai diesel
Model		SC8D185G2B1
Rated Power/Speed	kW/(r/min)	136/2000
Dimensiond	mm	6280×2320×3450
Engine number (optioanal)
Make		Cummins
Model		6BTA5.9-C180
Rated Power/Speed	kW/(r/min)	132/2200
Dimensiond	mm	6140×2320×3250
