flour grind mill raymond grinding mill mining grinding tube mill, Certification : CE & ISO, Motor Brand: Siemens - details see: https://www.machineto.com/shanghai-best-supplier-micro-powder-grinding-mill-price-10314738

Grinding Mills Grinding Mills Ball Mill Features:

Efficient tool for grinding many materials into fine powder
Used to grind many kinds of mine and other materials, or to select the mine
Widely used in building material and chemical industry
Two ways of grinding: dry and wet ways
Can be divided into tabular type and flowing type according to different expelling mine
To use the ball mill, the material to be ground is loaded into the neoprene barrel that contains grinding media
As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours
The longer the ball mill runs, the finer the powder will be
Ultimate particle size depends entirely on how hard the material you're grinding is, and the time how long the ball mill runs
Used to grind glass, powder food products, create custom varnishes, make ceramic glaze and powder various chemicals
Completely enclosed welded design in high-grade steel
Direct drive via bearing journal with top-mounted gearbox
Motor connected to gearbox via a V-belt drive
Product discharge via slots located around the periphery of the drum

Grinding Mills Key Specifications/Special Features:
Specifications:
Maximum weight of balls: 137T
Input size: ≤25mm
Output size: 0.074 to 0.4mm
Power: 800KW
Capacity: 0.5 to 2T/hour
Weight: 3.4T

Grinding Mills Features:
Large application range, simple structure and convenient maintenance
Large capacity and continuous work
Barrel lining and grinding media can apply various abrasive materials
Installation and adjustment are very convenient and easy to be operate

Ball Mill Grinder Specification:

Model	Max Feeding Size (mm)	Output Size (mm)	Ball Load (t)	Rotary Speed (r/min)	Capacity (t/h)	Power (kw)	Weight (t)
900×1800	≤15	0.075-0.89	1.9	37	0.5-2	15	3.4
900×2100	≤15	0.075-0.4	2.3	37	0.4-2	18.5	3.9
1200×2000	≤25	0.075-0.4	3.85	35	1.1-2.5	30	7.78
1200×2400	≤25	0.075-0.4	4.6	35	1.3-3.2	30	8.65
1200×2800	≤25	0.075-0.4	5.4	35	1.5-3.7	37	10.02
1200×4500	≤25	0.075-0.4	8.6	35	2.7-6.79	45	14
1500×3000	≤25	0.047-0.4	9	29	3.3-8.2	75	14.122
1500×4500	≤25	0.047-0.4	10.5	29	3.3-8.5	75	15.636
1500×5700	≤25	0.047-0.4	13.5	29	4.5-12	90	20

Picture for our ball mill grinder products

Picture for the final Powder products

Picture for the factory
