1.Product Name:Semi-automatic Cup-shaped Mask Machine,N95 mask forming machine, 2.Product Model:NODA-KZ2003 - details see: https://www.machineto.com/semi-automatic-cup-mask-production-equipment-10275548

Semi-automatic cup type mask production line

The specifications ofN95 Cup mask forming machine

1.Size:1100(L)*1100((W)*1800(H)MM
2.Efficiency:25--35PCE/MIN
3.Voltage:220V
4.Power:6500W

5.Weight:420KG

6.Air pressure:5kg/cm square area

7.Including feeding, one-time forming four to six masks, can work on both sides at the same time.

Brief introduction of N95 Cup mask forming machine

Cup type mask hot pressing molding machine, also called cup type mask forming machine, N95 respirator hot-pressing machine, used for the preliminary forming cup type mask.This machine is mainly use the principle of

hot pressing to finalize the design to complete cup type mask one-time molding machine.

The machine is divided into the following several: a simplex bit out of the four products, one out of four products of double location (double independent operation at the same time),

one out of six products of double location (double independent operation at the same time).

The specifications of N95 cup mask welding cutting machine

1.Size:1600(L)*1100((W)*1800(H)MM
2.Efficiency:10--20PCE/MIN
3.Voltage:220V
4.Power:4500W

5.Weight:300KG

6.Air pressure:5kg/cm square area

7.Characteristics of rotating disk cup type mask machine: ultrasonic disc flushed the cutting machine, cup type mask melt in design belongs to the industry leading level, in the industry enjoys high reputation.

Automatic cup type mask machine specifications
1.model:NODA-KZ2005
2.Machine size:2400mm*650mm*1500mm

3.Voltage: 220V, 50/60Hz

4.Efficiency: 50-60pcs/min

5.Power:1.5KW

6.Air pressure: 4-6kg/cm²

Automatic cup type mask machine features:

1.Pull the tube into the expected, the more accurate positioning, can make the raw material width control to a minimum, cost savings.

2.The finished product length size control and unified, deviation of plus or minus 1 mm, which can effectively control the length of the finished product, make the slice can not only meet the requirements of production process, and put an end to waste.

3. Independent feeding frame, convenient take put and adjusting the raw material.

Breathing valve punching machine equipment specifications

1.Model NO.:NODA-KZ2006

2.Size:600mm*540mm*1400mm
3.Efficiency:50-60PCE/MIN
4.Voltage:220V
5.Power:50W

6.Weight:40KG

7.Air pressure:6kg/cm square area

Breathing valve punching machine equipment features:
1. We can produce according to different types of masks, locating piece, punching accuracy, no error.
2. Speed, can be more than one cutting mask.
3. Easy to operate, can use a boot.
4. Quiet, no noise, the use of security than traditional punch.
5. The machine is small and exquisite appearance, does not occupy a space.

The specifications of mask nose bridge welding machine

1.Model NO.:NODA-KZ2007

2.Size:1200(L)*650((W)*950(H)MM
3.Efficiency:20--30PCE/MIN
4.Voltage:220V
5.Power:600W

6.Weight:50KG

7.Air pressure:5kg/cm square area

8.Category: Mask machine

The features of mask nose bridge welding machine

Applicable industry: disposables and medical industry

The bridge of the nose strip welding design, simple operation, on the principle of pneumatic drive, drive has good adhesive aluminum bar, after heating surface melt glue,

cylinder pushing its adhesion in the mask nose, a molding, welding shape effect is good, fastness is strong, and do not hurt surface of masks.

The specifications of mask spot welding machine

1.Model NO.:NODA-KZ2008

2.Size:800*600*1400MM
3.Efficiency:10--12PCE/MIN
4.Voltage:220V
5.Power:500W

6.Weight:50KG

7.Air pressure:5kg/cm square area

8.Category: Mask machine

The features of mask spot welding machine

1.The machine design flexible,convenient operation.

2.Can be used on flat surface, inner/outer ear, cup type mask, the duck mouth mask, and other special-shaped welding masks.

3.The production is completed, the mask ontology of ear with artificial welding, easy operation, welding strong and beautiful.

The specifications ofthe mask pad printing machine

1.Model NO.:NODA-KZ2009

2.Size:690mm*400mm*1295mm
3.Efficiency:20PCE/MIN
4.Voltage:220V
5.Power:50W

6.Weight:95KG

7.Air pressure:5kg/cm square area

8.Plate Maxsize: 100*150mm

The characteristics of the mask pad printing machine

1. The vertical structure, screen printing plate vertical lift, printing path for transverse scratch.

2. Adopts frequency conversion motor drive.

3. All adopt linear guide.

4. The printing pressure cylinder controlled by Japan.

5. Platform with vacuum suction,noise smaller.

6.Printing platform adopts high hardness materials, uniform porosity (production can be customized according to demand).

7. Printing platform equipped with X.Y.Z direction,can be fine-tuning.

8. Procedures set three modes:manual/semiautomatic/automatic (set according to production requirements).

9. Printing head bedplate, ink scraper/back knife, loading and unloading convenient cleaning.

10. Ink scraper/back knife Angle can be arbitrary adjusting.
