RW-500 semi-automatic aluminium foil rewinding machine

RW-500 semi-automatic aluminium foil rewinding machine, 1) half automatic, 2) rewinding, 3) for aluminium foil - details see: https://www.machineto.com/rw-500-semi-automatic-aluminium-foil-rewinding-machine-10333330

Condition:New	Type:Slitting Rewinder,rewinding,cutting machine	Computerized:Yes	Place of Origin:Zhejiang China (Mainland)
Brand Name:Aoxiang	Model Number:AXRW-500	Voltage:220 or change	Power(W):1.5kw
Dimension(LWH):1.4X1.1X1.1m	Weight:700kg	Certification:ce	Warranty:one year
After-sales Service Provided:Engineers available to service machinery overseas	automatic:half automatic	Rated Power:2kw	Application:plastic film
No-Load Rotational Speed:400m/min

Ⅰ.Feature:

1) This is a multifunctional equipment with the features of rewinding,metering,auto cutting, etc.

2) It is mainly used to slit and rewind jumbo roll of film membrane into several small volumes, and can improve the roll material’s flatness,appearance quality and other technical indications.

3) It is suitable for stretch wrap film,stretch film,preservative film,aluminum coated film,paper sheet, ect.

4) The maximum diameter of slitting is 700mm.

5) This machine is wildly applied in packaging,paper,supermarket,hotel,restaurant,cooked & uncooked food,fruit,seafood, etc.

Ⅱ.Main Technical Parameter:

Model	DR-RW-500
Width of finished products	500mm
Power of motor	1.5kw
Linear speed of machinery	400m/min
Roll laying mode	By hand
Diameter of parent roll(max)	400mm
Width of parent roll(max)	500mm
Core specification of parent roll	3"
Width of sub-roll	500mm
Diameter of sub-roll(max)	300mm
Core specification of sub-roll	3",2"
Overall dimensions	1.4X1.1X1.1m
Weight	700kg
