Rice mill flour machinery mill popular in Africa,Turkey

rice mill flour machinery:, 1. Hematite ore in Iron selecting line, 2. CCC and ISO 9001, 3. Energy saving - details see: https://www.machineto.com/rice-mill-flour-machinery-mill-popular-in-africa-turkey-10314768

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):15-800kw
Capacity(t/h):0.65-90t/h	Place of Origin:Henan China (Mainland)	Brand Name:Bailing	Model Number:BL
Dimension(LWH):as request	Weight:3.6-137t	Certification:ISO9001:2008 & CCC certificate	Warranty:1 year except wear parts
After-sales Service Provided:Engineers available to service machinery overseas	Color:any color is avaliable	Package:export standard	Motor:Chinese famous brand or as request
Installation:oundation drawing,guided by our senior engineer	OEM:Acceptable	Rotational speed(r/min):18-42	Balls weight(t):1.4-65

Rice mill flour machinery mill popular in Africa,Turkey

contact supplier for Rice mill flour machinery mill popular in Africa,Turkey

Rice mill flour machinery popular in Africa,Turkey

Discription:

This equipment uses automatic double row self-aligning spherical roller concentric bearings with less running resistance and Significant energy-saving effect. A conical cylinder is added to the original cylinder. This not only enlarges the effective

volume, but also makes medium distribution inside more reasonable. It is widely used in non-ferrous metals, ferrous metals, non-metallic mineral processing plant and chemical and building

materials industries as materials abrasive.

Structure:
The machine is composed of feeding part, discharging part, turning part and driving part (reducer,

small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the

liner is detachable. The turning gearwheel adopts casting hobbing process and the drum is equipped

with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable

working condition. Moreover, according to different materials and discharging methods, there are dry

ball mills and wet ball mills for choice.

Working principles:

The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred

to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and

different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel

brings the steel balls to a certain height and impact and grind the materials. The ground materials are

discharged through the discharging board thus the grinding process is finished.

Technical parameters:

Model	Diameter of Barrel mm	Length of barrel mm	Speed r/min	Power KW	Feeding Size mm	Discharge Size mm	Capacity t/h	Weight t
900×1200	900/675	900/300	41	Y7.5-6	15	0.075-0.8	0.3-0.8	3.08
900×2100	900/675	1800/300	41	Y15-6	15	0.075-0.8	0.5-2.1	3.9
1200×1600	1200/900	1200/400	35	Y17-6	20	0.075-0.8	0.8-2.2	6.2
1200×2000	1200/900	1600/400	35	Y22-6	20	0.075-0.8	1-2.6	7.2
1200×2800	1200/900	2400/400	35	Y37-6	20	0.075-0.8	1.5-4.2	9.2
1500×2000	1500/1200	1500/500	31	Y45-6	25	0.075-0.8	1.8-5	11.8
1500×3500	1500/1200	3000/500	32	JR75-6	25	0.075-0.8	3.3-8.4	15.6
1830×3600	1830/1600	3000/600	28	JR130-6	25	0.075-0.8	4.8-16.6	28
2100×3600	2100/600	3000/600	24	JR185-6	25	0.075-0.8	12.5-25	43.5
