grinding plant, 1Grinding pressure 800-1500kg, 2The minimum size of 1000 mesh, 3ISO, 415 years experience - details see: https://www.machineto.com/raymond-mill-3r-grinding-plant-10313990

grinding plant

Company profile:

Luoyang Shuangyong Machinery Manufacturing Co,.Ltd. is a pioneer enterprise in producing, designing mining technical plant.We supply such mining equipments –jaw crusher, impact crusher, cone crusher, grinding plant , belt conveyor to our worldwide customers.

grinding plant product Description:

grinding plantis a new research and development mill by Pioneer engineers based on many years mills R&D experience, the practical situation of the customers, and the needs of mill industry, which opens a new period of international mill industry marked by high efficiency and low power consumption

grinding plant Working Principle:

Materials are firstly crushed by jaw crusher, then transferred to grinding area by electromagnetic feeder through the elevator and lifted by the shovel to the sand belt formed by grinding roll and grinding ring. High-pressure springs are installed in the grinding device, helping improve rolling ability between grinding roll and ring by 1.2 times, reducing the swing frequency of grinding device, increasing stability and working efficiency of the mill at the same time. The grinded particles are brought up by the air current of the blower into the classifier for classification. The particles with required fineness are brought up by the air current through the pipe into a cyclone collector for separation and discharge while the unqualified returns to the main machine for a new grinding together with the air flow back to the blower. During the course of grinding, certain air flow circulates inside the machine through the pipe while the moisture of materials envaporates to the air return pipe and is purified by the cloth collector or pulse collector and finally discharged from the outlet.

grinding plant Advantages and Features:

1.Unique design. In the grinding chamber, we design a pressure device of 1500kg~2000kg on the plum-type shelf. The force of grinding device increases 800~1500kgf. Under the
same power, the capacity increases 10~30% and the fineness of products can be reached 1000 mesh.
2.Wide applications.Many materials with the Moh's hardness under 9.3.
3.Green.The effect of dust removing reaches to state standard.
4.Good airtightness. The grinding rollers apply the overlapping and multi-level air protection to make sure the efficiency and lengthen the working life.
5.Low operation cost. The wearing parts apply high quality materials to lengthen the grinding rollers and rings' working life. And also decrease the customers' investment cost.
6.Increase the use ratio of wearing parts.To ensure the stable capacity and fineness, customers can adjust the length of high-pressure spring and keep the invariable pressure between grinding rollers and rings.

grinding plant Main technical parameters:

Note: Any change of grinding plant technical data shall accord with Shuangyong’s actual products.

Company qualifications:

With strong technical power and production capability, grinding planthave been used in mining, houses construction, road & bridge building. Our company has achieved ISO9001:2008 international quality system certificate.

Company Equipment:

Our passionate management team which is committed to supply more economic, more convenient, better quality production plants for our customers will lead PIONEER into international machinery manufacturing and designing company.

The T6920D floor boring and milling machine

Plasma cutting machine HBCNC CNC cutting machine HBCNC

Supply perfect after-sale service

we offer a package service-foundation construction, equipment installation, device testing and operation guidance. Whether warranty expires, we will supply timely and thoughtful on-site maintenance.

we give you operation training on customer site to let end-users know how to reduce repair times, prolong usable life of equipment and improve efficiency. Moreover, we will teach end-users to know the structure design, working principle, basic maintenance and fault treatment methods.

we also supply free survey of present equipments conditions and configuration, suggest you one more economic configuration.

High quality, Most reasonable, Most economic, that is our standard for our honored customers.

For more ball press machine,raw grinding machines, grinding plant ,crushers equipments,mill machines ,ball press, please view our website: http://lysyzg.en.alibaba.com/
