radial drilling press Z3032

radial drilling machine, 1.ISO 9001:2008,, 2.certificate for product export,, 3.max. drilling in steel 32mm in cast iron 40mm. - details see: https://www.machineto.com/radial-drilling-press-z3032-10125479

Condition:New	CNC or Not:Normal	Place of Origin:Guangxi China (Mainland)	Brand Name:JINSIANGSHAN
Model Number:Z3032	Voltage:380V	Power(W):3 kw	Dimension(LWH):1730746235 cm
Weight:1500 KG	Certification:CCC	After-sales Service Provided:Engineers available to service machinery overseas	Processing Types:Metal
Usage:Drilling hole	Controlling Mode:Electrical power

contact supplier for radial drilling press Z3032

Features: 1) Compact design, beautiful appearance, easy to maintenance2) Manual clamping mechanisms, wide speed and feed range3) Compactly operating, reliable and good mobility4) Has a supper rigidity and power in drilling5) Drilling, reaming, counter boring, boring, tapping6) Widely used in every department of mechanical machining

Description			Z3032×8	Z3032×10	Z3032×13
Maximum drilling diameter		mm	32
Distance from the centre line of spindle to column	Max	mm	800	1000	1300
	Min	mm	200
Horizontal traverse of spindle head on arm		mm	800
Distance from spindle nose to working surface of base plate	Max	mm	1064
	Min	mm	264
Vertical travel of arm on column		mm	550
Elevating speed of arm		m/s	1.13
Swivel angle of arm		degree	360 °
Taper in spindle		morse	4
Range of spindle speeds		r/min	71 ~1800
Number of spindle speeds		steps	8
Range of spindle feeds		mm/r	0.13 ~0.54
Number of spindle feeds		steps	4
Spindle travel		mm	250
Feed depth per revolution of graduated dial		mm	102
Maximum permissible torque of spindle		N ·m	250
Maximum permissible feed pressure of spindle		kN	10
Power of the main drive motor		kw	2.2
Power of arm elevating motor		kw	0.75
Power of coolant pump motor		kw	0.06
Weight of the machine(approx.)		kg	1180	1200	1230

Accessories:

No.	Specification &Type No.	Description
Technical Documents
1		Operation Manual
2		Test Certificate
3		Packing List
4
Main Frame
1	Model Z3032×10	Radial Drilling Machine
Accessories
1	450×400×400	Working Table
2	M20;J11-3	Finishing hexagon nut
3	M20×370;J23-8	Foundation bolts
(3)	M20×300;J23-8	Foundation bolts
4	M20×85;J29-1	T-slot bolt
5	20;J51-1	Finishing washer
6	1;2;3;SZSS81-1	Drift
(7)	4;SZSS81-1	Drift
7	2×1;3×2;SZSS82-1	Morse taper short reducing
8	4×3;SZSS82-1	Morse taper short reducing
9	90;SZSS81-1	Oil gun
