Powerful ball-bearing mill, popular in henan bailing

Powerful ball-bearing mill, popular in henan bailing, 1.Both dry and wet grinding types available, 2.Longer linning service - details see: https://www.machineto.com/powerful-ball-bearing-mill-popular-in-henan-bailing-10314757

Condition:New	Type:Ball Mill,ball-bearing mill	Motor Type:DC Motor	Power(W):.
Capacity(t/h):0.65-90t/h	Place of Origin:Henan China (Mainland)	Brand Name:Bailing	Model Number:bl
Dimension(LWH):.	Weight:.	Certification:ISO9001	Warranty:12months
After-sales Service Provided:Engineers available to service machinery overseas	Application:Ore,limestone,rock	liner:rubber, ceramics, silica, Mn steel, ect	power consumption:energy-savig type
QA/AC:ISO9001:2000	installation:guide by our engineers	Grinding way:Wet or dry	Feeding granularity(mm):≤25
Min discharg size:0.074mm

Application of Ball Mill:

The ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc. And the ball mill can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.

Advantages of Ball Mill:

We have the good service to our customers, if they can't install the machines, we can send our technician come to your location, and install for you. We make every endeavor to satisfy our customers.

Main Technical Parameters:

Model	Speed of bucket (r/min)	Weight of ball (t)	Size of feed opening (mm)	Size of output size (mm)	Production (t/h)	Power (kw)	Weight (t)
φ900×1800	38	1.5	≤20	0.075-0.89	0.65-2	18.5	3.6
φ900×3000	38	2.7	≤20	0.075-0.89	1.1-3.5	22	4.6
φ1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	45	12.5
φ1200×3000	32	5	≤25	0.074-0.4	1.6-5	45	12.8
φ1200×4500	32	7	≤25	0.074-0.4	1.6-5.8	55	13.8
φ1500×3000	27	8	≤25	0.074-0.4	2-5	90	17
φ1500×4500	27	14	≤25	0.074-0.4	3-6	110	21
φ1500×5700	27	15	≤25	0.074-0.4	3.5-6	132	2407
φ1830×3000	24	11	≤25	0.074-0.4	4-10	180	28
φ1830×6400	24	23	≤25	0.074-0.4	6.5-15	210	34
φ1830×7000	24	25	≤25	0.074-0.4	7.5-17	245	36
φ2200×5500	21	30	≤25	0.074-0.4	10-22	370	48.5
φ2200×6500	21	30	≤25	0.074-0.4	14-26	380	52.8
φ2200×7500	21	33	≤25	0.074-0.4	16-29	475	56
φ2400×3000	20.6	15.5-15.6	≤25	0.074-0.4	15-55	245	59
φ2400×4500	21	30	≤25	0.074-0.4	15-60	380	65
φ2700×4000	20.6	40	≤25	0.074-0.4	20-80	400	94
φ2700×4500	20.7	48	≤25	0.074-0.4	20-90	430	102
φ3200×4500	18	65	≤25	0.074-0.4	According to different tech	800	137
