veneer drying machine BG1933, design as customer requirement - details see: https://www.machineto.com/plywood-veneer-dryer-machine-10344006

Mess-Roller Combined Veneer Dryer BG1933

Theveneer dryerapparatus is the main parts in plywood industry, and used to remove moisture from the veneer. The heat medium can be thermo oil and heat steam. The whole machine can be divided into two parts: heating section and cooling section. All the instruction can be operated in switch board. We can design the veneer dryer as customer`s project requirement.

The main specification:

Model	BG183	BG183A	BG1332	BG1333
Working width (mm)	2650	2650	2800	2800
					Working decks (layer)	2	3	2	3
Length of heating section (mm)	2000x11=22000	2000x13=26000	2000x8=16000	2000x13=26000
Lengtheof cooling section(mm)	2000x1	2000x2	2000x1	2000x1
Transmission speed (m/min)	2-28	2-28	1.5-15	1.5-15
Drying capacity (m3/h)	2.5-3.2	5-5.8	1.8-2.5	4.8-5.5
Steam consumption (kg/h)	1800-2000	3000-3600	1500-2000	2800-3000
Total motor power (kw)	95.7	190	72.3	168.5
Transmission motor power(kw)	11	33	11	18.5
Calorifier motor power (kw)	7.5 x 11	11 x 13	7.5 x 8	11 x 13
Cooling Fan power (kw)	2.2 x 1	(3+4) x2	2.2 x 1	3+4
Overall dimensions (mm)	28760 x 4860 x 2940	395000 x 5200 x 4950	23000 x 4215 x 2670	46000 x 5400 x 4150
Weight (kg)	38000	88000	32000	98000

---

Model	BG1932	BG1933A	BG1933B
Working width (mm)	2650 net	2650 net	2650 net
	2800 roller	2800 roller	2800 roller
Working decks (layer)	2	3	3
Length of heating section (mm)	2000x10=2000	2000x13=26000	2000x13=26000
Lengtheof cooling section(mm)	2000x1	2000x1	2000x1
Transmission speed (m/min)	2-28net, 1.5-15roller	2-28net, 1.5-15roller	2-28net, 1.5-15roller
Drying capacity (m3/h)	1net, 1.2roller	3.2net, 1.8roller	1.8net, 3.6roller
Steam consumption (kg/h)	2000	2800	3000
Total motor power (kw)	88.2	163.9	170.5
Transmission motor power(kw)	11	16.5	20.5
Calorifier motor power (kw)	7.5 x 10	11 x 13	11 x 13
Cooling Fan power (kw)	1.2 x 1	2.2 x 2	3+4
Overall dimensions (mm)	26760 x 4260 x 2940	34260 x 5400 x 4550	34260 x 5400 x 4430
Weight (kg)	40000	88000	95000
