Piston filling plant for liquid
| Place of Origin:Zhejiang China (Mainland) | Brand Name:accurate | Model Number:AVF-6 |
AVF series automatic viscosity filling machine is designed by referring to the same kind of foreign filling machines with extra functions increased. The product is simple and convenient in operation, error correction, machine cleaning and maintenance. Widely used for filling various kinds of viscosity liquid products in the industries of daily chemicals, foodstuffs, pharmaceutics and oil etc.
Characteristic:
Adopt injection pump to fill high precision, large range of adjusting dosage.
It allows to adjustment of filling volume for all filling pumps at the same time, also for minor adjustment of each filling pump to achieve fill high volume accuracy.
This pump system don't absorb the material, good chemical stability, It has particular advantage when filling erosive material.
All contact parts is made of ss 316L and silicone tube, be convenient to clean by CIP.
Filling system has the function of shrinking, no drop leak.
Apply to fill various viscosity liquid.
All of electric elements choose famous brand such as Italy AT, Japan Mitsubishi and Korea AUTONICS.
Frequency conversion control speed, auto count.
The whole machine is designed according to requirements of GMP.
| ITEMS | AVF-4 | AVF-6 | AVF-8 | AVF-12 | AVF-16 |
| Filling nozzles | 4 | 6 | 8 | 12 | 16 |
| Ideal filling range | 100-500ml\200ml-1000ml\500-2000ml\2000-5000ml | ||||
| Filling speed bpm | 10-20 | 20-30 | 30-40 | 50-60 | 70-80 |
| Filling precision | ≤ ± 1% | ||||
| Air pressure range | 0.4~0.6MPa | ||||
| Air consumption | 10M3/h | 15M3/h | 20M3/h | 30M3/h | 40M3/h |
| Power supply | 220V 50/60Hz, single phase | ||||
| Power consumption | 0.75kw | 0.75kw | 1.2kw | 2.2kw | 2.2kw |
| Single machine noise | ≤ 50dB | ||||
| Net weight | 550kg | 900 kg | 1100kg | 1300kg | 1550kg |
| Overall dimension (mm) | 1300× 1200 × 1800 | 1600× 1200 × 1800 | 1900× 1200 × 1800 | 2300× 1200 × 1800 | 2600× 1200 × 1800 |
| Packaging Detail:wooden pakage |
| Delivery Detail:30 days |
