most popular ultrafine grinding mill ball mill powder grinder

Introduction of grinding mill:

Ultrafine powder grinding mill is researched and developed by our technologist according to advanced domestic and foreign technology . Its take advantages of the traditional grinding mill, ball mill, circulate air micro powder grinding mill, high pressure suspension grinder mill and so on, environmental and new generational micro powder grinding mill has been developed successfully, whichhas two-grade and two-chamber converter and classify technique characters: compact equipment, beautiful appearance, reasonable design, no pollution ,little noise, higher fineness, save time and power, and easy to operate, it’s optimal to choose, “grinder mill king” called by the international friends.and the hardness of this machine is up to 10 grades. Fineness of its products can reach 500-5000 meshes(25um-26um) for special material ;can reach 8000 meshes(1.6um).it is a good grinding mill with highest product fineness ,grinding highest hardness material at present.

Features of ultrafine grinding mill :

1,	Wehas solved axletree and bolt flexible leading to the equipment damage’s problems
2.	This machine adopts vertical double stage double room alloy steel ball grinding device, and the active grinding plate driven the steel ball rotation to grind materials,solve replace frequently vulnerable parts about the dust flies in grinding machine, grinding roller, grinding ring, and axletree’s problem
3.	This machine adopts the high strength hydraulic device; increase the working pressure 6-20tons of using alloy steel ball grinding plate, thusadding the material of force grinding speed
4.	This machinehas two-stage grinding chamber, fine degree is higher, high output, solve the problem of traditional single stage and low fineness and low yield
5.	This machineuses double frequency converse technology, multilevel discharge; accurate classify is up to99%,solve the problem of unclear classification
6.	Toimprove anti-friction, high quality steel ball and the paragon steel grinding dischas been used to this machine
7.	The machine’s transmission takes vertical moderator, vertical drive axle, the grinding disc is working under vertical axles’moving, and there is no bolt and axletree from the vertical axle to grinding disc, smoothly working.Solve the conventional grinding mill’s problems of exchanging for axletree, bearing bush, and axle sleeve
8.	This machine takes negative pressure working tosolve dusts going out under positive pressure of traditional grinding mill’s fan
9.	This machinetakes the transmission classify, cyclone feeder, four stages cyclone feederto make grading and semicolon
10.	Double cabinet sound insulation device has been assembled to this machine’s shell, and mute and the air filter device has been used to the fan. They are used to decrease noise, pulse filter and air filter deviceget rid of the dust, there is no dust, no noise, furthermore, environment-friendly
11.	This machinetakes low rotate speed, negative pressure cooling system to keep cooling and the character of material while grinding, at the same time solves the traditional ultrafine powder grinding and pulverizer could not keep the original nature
12.	There isno axletree, avoiding polluting material by oil spilling
13.	This machine is widely applicable to height, medium, low etc. all kinds ofmaterial Moh’s hardness class under 10
14.	Product fineness is higher,finished fineness could be adjusted 500-5000mesh, to special material could be 8000 meshes

Technical data of grinding mill:

Item		88A	88B	88C	1010A	1010B
Motor of principle machine(kw)		30kw-6 grades	30kw-6 grades	18.5kw-6 grades	45kw-6 grades	45kw-6 grades
Motor of No. 1 classifier(kw)		11kw-2 grades	7.5kw-2 grades	/	11kw-2 grades	11kw-2 grades
Motor of No. 2 classifier(kw)		11kw-2 grades	11kw-2 grades	/	15kw-2 grades	15kw-2 grades
Motor of No. 3 classifier(kw)		15kw-2 grades	/	/	22kw-2 grades	/
Adjustable motor (kw)		/	/	4	/	/
Motor of fan (kw)		30kw-2 grades	22kw-2 grades	18.5kw-2 grades	37kw-2 grades	37kw-2 grades
Motor of feeder(kw)		0.06	0.06	0.06	0.06	0.06
Motor of bucket elevator (kw)		3kw-4 grades	3kw-4 grades	3kw-4 grades	3kw-4 grades	3kw-4 grades
Hydraulic pressure(T)		6-20T	6-20T	6-20T	6-20T	6-20T
Output(kg/h)		100-2500	100-2500	100-2000	200-3500	200-3500
Size of input(mm)		<5	<5	<5	<5	<5
Size of final product	um	150-2.6	150-5.5	150-6.5	150-2.6	150-5.5
	mesh	100-5000	100-3000	100-2000	100-5000	100-3000
Hardness of raw material (Moh’s hardness, grade )		1-10	1-10	1-10	1-10	1-10
Total power (kw)		100.06	73.56	44.06	133.06	111.06
Dimensions(l×d×h)(m)		17.5×3.2×5.5	15×3×5.5		17.5×3.2×5.5	15×3×5.5

Pictures of grinding mill:

Our superior sevrice:

1,designing and manufacturing the products according to your requirement.

2,training the workers to operate the machine.

3,supply the best quality and lowest price products.

4,install and adjust machine until its running well.

5,we have superior after-sales sevrice ,if in period of processing ,we can arrange our technican to fix it until you are satisfied with it .
