1. CNC: Delem, 2. parts brand: Siemens/Weidmuller/Schneider, 3. steel parts: heat treatment, 4. mechanical torsion synchrony - details see: https://www.machineto.com/metal-working-machine-cnc-hydraulic-press-brake-machine-300t-6200-10123963

Metal Working Machine: CNC Hydraulic Press Brake Machine 300T/6200

1. The W67K press brake has 300tons of bending force over it full6200mmframe. The Frame on this hydraulic press brake is made from fully welded steel plate designed to give minimum amounts of deflection as well as offer maximum rigidity. The W67K also features a heavy duty torque tube that connects a pair of hydraulic cylinders ensuring accuracy to .04mm. As with all JSJR press brakes, the W67K uses only top quality components from manufacturers like,Siemens, Estun.

2. The worktable, upper and bottom die, sliding rail, back gauge, etc. are conducted quenching treatment, which keeps the parts high hardness, less deformation and wear out, thus maintain the stability of machine tool accuracy, prolongs the service life.

3. Another nice feature of the W67K press brake is a two axisDROthat monitors the powered back gauge and the bend depth making this one easy to use press brake at an incredible price. All bending functions, whether it is full auto or jog mode, are controlled by a foot pedal. The W67K comes standard with a gooseneck punch and afour-sided multi-V bottom die.

4. For more information on this or any of the other great JSJR products, contact a JSJR representative.

Nominal POWER	3000Kn
Table Length	6200mm
Throat Depth	400mm
Stroke Distance	345mm
gear pump	16L/min
Main Motor	7.5KW
cnc system	Delem41
Distance Between Housings	4600mm
Stroke adjustment of Ram	150mm
max working speed of back gauge	300mm/s
repeat location accuracy of back gauge	0.02mm
sliding block traveling speed	Fast down: 120mm/s
	Slow down: 10mm/s
	Return: 80mm/s
sliding block repeat location accuracy	0.01mm
WORKPIECE STRAIGHTNESS	0.3/M
Shipping Weight	7300Kg
Shipping Dimensions	3260 X 1450 X 2580mm

JIANGSU JIURI CNC MACHINERY CO., LTD. makes both CNC and standard metal shearing machine, hydraulic press brake, and metal rolling machine.

We exported a lot in the past to Asia, Africa, and South America. Our factory is one of the best manufacturers in our country.

We can make special orders for customer who have special requirement of machines.

We welcome customers from everywhere in the world come to visit our factory.
