Medium crushing cement ball mill cement crushing plant for sale

Product Description

This series ball mill is widely used in black, non-ferrous metal mining, building materials, chemicals, electricity, coal, transportation, light industry and other industrial sectors. Our high-efficiency and saving-energy ball mill adopts rolling bearing substituting for sliding bearing, which can save energy 10-20% compared with sliding bearing. Adopting oil grease in place of thin oil lubrication station, and large-type mill needs not to be equipped with high-and-low pressure lubrication station with high cost.

Lattice-type ball mill has lattice panels at the discharge end, with more volume of ball, larger installation power, higher capacity and more coarse discharge granularity and usually used in primary crushing; Spill-over ball mill are usually used in fine grinding with lattice panels at the end and with higher discharge opening, less volume of ball, smaller installation power, lower production capacity and finer discharge granularity.

Performance Parameter

Model	Barrel Size (mm)	Bareel Volume(m3)	Ball Load(t)	Barrel Speed(r/min)	Power (kw)	Outlet Size (mm)	Capacity (t/h)
	Dia. X Length
GMQG1530	1500*3000	4.0	8	27.6	75	0.8-0.074	12-2.8
GMQG1535	1500*3500	4.6	11	27.6	75-90	0.8-0.074	14-3.4
GMQG1830	1800*3000	6.5	13	25.3	132	0.8-0.074	21-4.8
GMQG1835	1800*3800	7.58	16	25.3	160	0.8-0.074	25-5.8
GMQG1840	1800*4000	8.65	17.3	25.3	185	0.8-0.074	28-6.6
GMQG1845	1800*4500	9.75	19.5	25.3	210	0.8-0.074	31-7.2
GMQG2122	2100*2200	6.7	14.7	23.8	160	0.8-0.074	24-5.3
GMQG2130	2100*3000	9.2	17	23.8	185	0.8-0.074	26-6.0
GMQG2136	2011*3600	11.0	19	23.8	210	0.8-0.074	29-6.5
GMQG2140	2100*4000	12.2	20.5	23.8	220	0.8-0.074	32-7.2
GMQG2145	2100*4500	13.8	22	23.8	250	0.8-0.074	36-8.1
GMQG2424	2400*2400	9.8	20	22.8	220	0.8-0.074	32-6.6
GMQG2430	2400*3000	12.2	25	22.8	250	0.8-0.074	38-7.5
GMQG2436	2400*3600	14.6	30	22.8	280	0.8-0.074	42-8.5
GMQG2440	2400*4000	16.2	33	22.8	355	0.8-0.074	47-9.5
GMQG2445	2400*4500	18.2	37	22.8	400	0.8-0.074	55-10.5
GMQG2721	2700*2100	10.7	24	21.7	280	3.0-0.074	84-8.5
GMQG2727	2700*2700	13.8	29	21.7	315	3.0-0.074	105-9.0
GMQG2730	2700*3000	15.3	32.5	21.7	355	3.0-0.074	120-10
GMQG2736	2700*3600	18.4	39	21.7	400	3.0-0.074	145-12
GMQG2740	2700*4000	20.5	43	21.7	450	3.0-0.074	159-13
GMQG2745	2700*4500	23.0	50	21.7	500	3.0-0.074	180-15
GMQG3231	3200*3100	22.65	46.9	18.6	500	3.0-0.074	182-16
GMQG3236	3200*3600	26.2	52	18.6	560	3.0-0.074	190-19
GMQG3240	3200*4000	29.2	57	18.6	630	3.0-0.074	210-22
GMQG3245	3200*4500	32.8	65	18.6	710-800	3.0-0.074	235-29
GMQG3254	3200*5400	39.2	81.6	18.6	800-1000	3.0-0.074	280-35
GMQG3640	3600*4000	35.6	75	17.3	800	3.0-0.074	230-25
GMQG3645	3600*4500	40.8	88	17.3	1000	3.0-0.074	259-29
GMQG3650	3600*5000	45.3	96	17.3	1120	3.0-0.074	288-35
GMQG3660	3600*6000	54.4	117	17.3	1250-1500	3.0-0.074	310-38
GMQG3685	3600*8500	79.0	144	17.3	1800	3.0-0.074	450-5

Application Case

Certification

To give you a responsible quotation, you can inform us the following information:

1). What's the material you are going to deal with?

2). What's the granularity of the material?

3). What's the granularity of the final products are you going to achive?

4). What's the producing capacity you are going to achieve?

Ourball millengineer will suggest you the most suitable one for you according to your information.
