made in China Dongfeng 12m3 chemical liquid water truck

Facebook Twitter LinkedIn Google Google+

made in China Dongfeng 12m3 chemical liquid water truck

Specifications
oil tank truck Useful volume 22m3 ive strohouses D310-S1 single-bedroom standard air-condition
Model				EQ5254G
Engine				Commins C260 20
PowerKW				221
Displacementml				8300
Cylinder bore				114×135
Fuel type				diesel
Type of engine				straight-six,turbo-supercharged,intercooled
Useful volume				22m3 five strohouses
Cab				D310-S1 single-bedroom standard air-condition
Clutch				Φ430mm Diaphram spring
Front axle				7T beam girder structure
Rear axle				10T*2 main reduction ratio:i=4.44
Wheelbase(mm)				5650+1300
Frame				300×90×(8+6)
Number of spring				8
Gearbox				DC9J150TJ
Overall (L x W x H) (mm)				11540 ×2480 ×3030
Approach / departure angle				20/14
Mini ground clearence(mm)				248
Curb Weight (kg)				9225
Max. mass of chassis				25000
Drive Former				4×2
Tire Size				11.00R20
Max. grade ability(%)				30
Vmax (km/h)				90
Mini. Turning diameter(m)				22.5
Oil consumption(L/100km)				28
