1. Short drying time, 2. Easy to operate, labor intensity is low, 3. Easy to clean, 4. GMP, 5. High efficiency - details see: https://www.machineto.com/lpg-ceramic-powder-spray-dryer-ceramic-spray-dryer-spray-dryer-10295772

1. General description of Ceramic Dryer:

Spray dryer is suitable for solution, suspension, slurry, paste material, etc. Liquid material is atomized to small fog drops. And fog drops contact with hot air directly in the drying tower. Moisture content is evaporated instantly. So spray dryer features high efficiency, high mass transfer area, and short drying time, in general it is 5~30 seconds. Operating temperature can be adjusted according to actual situation, in general inlet air temperature is 150~500°C. And its automation control degree is control, environment solution environment can be solved.

2. Features ofCeramic Dryer:

1. Quick drying speed, the surface area of material liquid through atomizing is increased greatly. In hot air stream, 95%~98% of moisture can be evaporated at moment. Particularly suitable to finish drying thermal sensitive material.
2. The product made by the machine has good uniformity, fluidity, solubility, high purity, and high quality.
3. The productive process is simple and the operation control is very convenient. For liquid containing is 40%~60% (for special material, may be 90%), it can be dried to powder product through drying one time. After dried, it is not necessary to crush and sieve. So it reduces productive procedure and raises the purity of product. For the size, bulk density and moisture of product can be adjusted within certain scope through changing operation condition. The control and management are very convenient.

3. Technical parameters ofCeramic Dryer:

Item	LPG
	5	25	50	100	150	200-3000
Inlet air temperature	≤ 350°C
Outlet air temperature	80-90°C
Evaporate capacity (kg/h)	5	25	50	100	150	200-3000
Driving type	compressed air drive	mechanical drive
Rotary speed	25000	22000	21500	18000	18000	15000
Diameter of atomizer tray (mm)	50	120	120	120	150	180-340
Heating source	Electricity	Electricity	electricity +steam	electricity +steam	To be solved by users	To be solved by users
Electric-heating power (kw)	9	45	60	81	99
Dried powder recovery rate (%)	≥ 95	≥ 95	≥ 95	≥ 95	≥ 95	≥ 95

4. On Site pictures
