Low price China grinding mill Manufacturers with BV Certificates

China grinding mill features:, 1)Reduce the energy consumption by 30%, 2)Improve fineness of discharging, 3)BV,SGS - details see: https://www.machineto.com/low-price-china-grinding-mill-manufacturers-with-bv-certificates-10314796

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):22-800 kw
Capacity(t/h):1.1-80 t/h	Place of Origin:Henan China (Mainland)	Brand Name:Defy	Model Number:1500*3000mm
Dimension(LWH):300015001500mm	Weight:5.6-137t	Certification:ISO,BV	Warranty:1 year(wearing parts exclude)
After-sales Service Provided:Engineers available to service machinery overseas	Application:cement,silicate,refractory material,fertilizer	Most feed-in size:25mm	Installation:engineer guide
After sale serivice:Installation,commissioning	Guarantee:1year(wearing parts excluded)	Wear parts supply:whole using life	Performance:stable and energy saving
MOQ:1 set	Color:as requested	Price:negotiable

Low price China grinding mill Manufacturers with BV Certificates

contact supplier for Low price China grinding mill Manufacturers with BV Certificates

Ball mill is Defy's major product, professional technology support and all-around service can be offered to you, we also can made according to your special requirments. Welcome you visit our company to know more about us!

ball mill is key equipment to grind all kinds of ores and other materials.which is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc.

Ball Mill consists of feed&discharge parts, rotary shell, transmission part and other major components.Hollow shaft is with steel parts, lining is removable. Rotary gear adopts casting hobbing, and the tube body is with resisting liner.

The advantages of Ball Mill

1.Large application range,simple structure and convenient maintenance.

2.Large capacity and continuous work are very obvious.

3.Barrel lining and grinding media can apply various abrasive materials.

4.Installation and adjustment are very convenient and easy to be operated.

Ball Mill parameter

Model	Rotation speed of the chamber (r/min)	Ball load (t)	Feed-in size (mm)	Feed-out size (mm)	Output (t/h)	Power (kw)	Weight (t)
900×3000	36	2.7	≤20	0.075-0.89	1.1-3.5	22	5.6
1200×2400	36	3	≤25	0.075-0.6	1.5-4.8	30	12
1200×3000	36	3.5	≤25	0.074-0.4	1.6-5	37	12.8
1500×3000	29.7	7.5	≤25	0.074-0.4	2-5	75	15.6
1500×5700	28	12	≤25	0.074-0.4	3.5-6	130	24.7
1830×3000	25.4	11	≤25	0.074-0.4	4-10	130	28
1830×4500	25.4	15	≤25	0.074-0.4	4.5-12	155	32
2100×3000	23.7	15	≤25	0.074-0.4	6.5-36	210	34
2100×4500	23.7	24	≤25	0.074-0.4	8-43	245	42
2200×4500	21.5	27	≤25	, 0.074-0.4	9-45	280	48.5
2200×6500	21.7	35	≤25	0.074-0.4	14-26	370	52.8
2400×4500	21	30	≤25	0.074-0.4	8.5-60	320	65
2700×4000	20.7	40	≤25	0.074-0.4	12-80	400	94
3200×4500	18	65	≤25	0.074-0.4	/	800	137

Ball Mill installation site

Ball Mill Customer Site

Product payment terms
1) Accepted small order
2) Ready to ship out within by sea, as soon as we receive payment.
3) We accept T/T. Western Union, L/C.

After sale service & promise:
1,supply OEM&ODM order,independent Q.C department ,3 times of quality checking,
2.100% percent of pass before shipping
3.one year of warranty ,supply wear parts whole using life
4.BV,SGS certification

Anne Bai

Zhengzhou Defy Mechanical&Electrical Equipment Co., Ltd.

Skype:defy08

TM:cn1501435969

Mobile:0086-371-15136212564

Tel: 0086-371-55819257

Packaging Detail:The main machinery is in nude packing,and spare parts in Wooden or steel box standard export packing, suitable for long distance delivery.

Delivery Detail:Within 25 days after receiving the prepayment
