Lonking 5ton diesel forklift truck

Internal Combustion Forklift, Equipped with Chaochai Engine or Imported Isuzu Engine, Advanced Ergonomical Design, Large Capacit - details see: https://www.machineto.com/lonking-5ton-diesel-forklift-truck-10109846
Condition:NewPlace of Origin:Shanghai China (Mainland)Brand Name:LONKINGModel Number:LG50DT
Power Souce:Diesel EngineRated Loading Capacity:5000KGMax. Lifting Height:6MMin. Lifting Height:3M
Fork Length:1220mmFork Width:150mmOverall Dimensions:4660x2000x2500Certification:CE
After-sales Service Provided:Engineers available to service machinery overseascolor:yellow
Lonking 5ton diesel forklift truck
contact supplier for Lonking 5ton diesel forklift truck


MODELLG50DT
Power typeDiesel
Rated capacity (Kg)5000
J Load centre (mm)600
h1 STD Max lifting height (mm)3000
h3 Free lift height (mm)200
L5×W×T STD Fork size (mm)1220×150×60
Mast tilt angle (deg)6/12
L3 Front overhang (mm)589
L4 Rear overhang (mm)645
Overall dimension
L1 Overall Length(with fork) (mm)4704
W1 Overall width (mm)2000
h2 Mast lowered height (mm)2500
h4 Overhead guard height (mm)2480
R1 Min. turning radius (mm)3370
Min. turning aisle (mm)5400
Speed(load/unload)
Max. traveling speed (km/h)24/25
Max. lifting speed (mm/s)350/450
Max. gradient (%)20
Dead weight (kg)8600
S/P Tread(front/rear) (mm)1470/1700
L2 Axle distance (mm)2250
Min.ground clearance
m2 Mast (mm)201
m1 Frame (mm)248
STD EngineChaochai CY6102BG
Rated power81kW
Lonking 5ton diesel forklift truck
Packaging Detail:standard packing
Delivery Detail:20 days after advance payment
