Limestone Ball Mill Grinding Machine

Limestone Ball Mill, *ISO9001:2000 certificate, *Wearable barrel body, *Hollow axis adopts cast steel, *Lining plate can change - details see: https://www.machineto.com/limestone-ball-mill-grinding-machine-10314296

Condition:New	Type:Ball Mill	Power(W):18500-800000	Capacity(t/h):0.25-90
Place of Origin:Henan China (Mainland)	Brand Name:sx	Model Number:various	Weight:4.6-137(t)
Certification:ISO9001:2000	Warranty:one year	After-sales Service Provided:Engineers available to service machinery overseas	Certificate:ISO9001:2000
Guarantee:1 year excluding easily wearing parts	Installation:with our engineer's guidance	Color:by request

contact supplier for Limestone Ball Mill Grinding Machine

Application of Limestone Ball Mill

Ball mill is the key grinding equipment after the crushing process. It is widely used in the many industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics. According to the discharging ways of ore, ball mil can also be divided into the grid type and the overflow type.

Great features of Limestone Ball Mill

1. The barrel body is wearable and bears wearable scale board.

2. This ball mill runs steadily and works efficiently.

3. High technology, easy operation, energy saving, lower noise.
4. The ball mill is made up of feeding part, discharging part, gyre part, transmission part (reducer, small transmission gear, motor, and electrical controller) and so on.

5 The hollow axis adopts the cast steel, and the lining can be replaced. The big rotary gear is forged from cast rolling gears.

6. The barrel body is inlaid with wearable plates.

Main technical parameters of Limestone Ball Mill

Model	Cylinder speed (r/min)	Weight of ball(t)	Input size(mm)	Output size(mm)	Capacity(t/h)	Power (kw)	Weight (t)
900×1800	36~38	1.5	≤20	0.075-0.89	0.65-2	18.5	4.6
900×3000	36	2.7	≤20	0.075-0.89	1.1-3.5	22	5.6
1200×2400	36	3	≤25	0.075-0.6	1.5-4.8	30	12
1200×3000	36	3.5	≤25	0.074-0.4	1.6-5	37	12.8
1200×4500	32.4	5	≤25	0.074-0.4	1.6-5.8	55	13.8
1500×3000	29.7	7.5	≤25	0.074-0.4	2-5	75	15.6
1500×4500	27	11	≤25	0.074-0.4	3-6	110	21
1500×5700	28	12	≤25	0.074-0.4	3.5-6	130	24.7
1830×3000	25.4	11	≤25	0.074~0.4	4-10	130	28
1830×4500	25.4	15	≤25	0.074~0.4	4.5-12	155	32
1830×6400	24.1	21	≤25	0.074~0.4	6.5-15	210	34
1830×7000	24.1	23	≤25	0.074~0.4	7.5-17	245	36
2100×3000	23.7	15	≤25	0.074-0.4	6.5-36	155	42
2100×4500	23.7	24	≤25	0.074-0.4	8-43	245	42
2100×7000	23.7	26	≤25	0.074-0.4	8-48	280	50
2200×4500	21.5	27	≤25	0.074-0.4	9-45	280	45.5
2200×6500	21.7	35	≤25	0.074~0.4	14-26	380	52.8
2200×7000	21.7	35	≤25	0.074-0.4	15-28	380	54
2200×7500	21.7	35	≤25	0.074~0.4	15-30	380	56
2400×3000	21	23	≤25	0.074-0.4	7-50	245	54
2400×4500	21	30	≤25	0.074-0.4	8.5-60	320	65
2700×4000	20.7	40	≤25	0.074-0.4	12-80	400	94
2700×4500	20.7	48	≤25	0.074-0.4	12-90	430	102
3200×4500	18	65	≤25	0.074-0.4	according	800	137
