EXLAS1410 laser Textile cutting or engraving machine

Machine Description	EXLAS-1410 Laser Engraving and Cutting Machine
Machine Performance:
Laser-type	Hermetic and detached CO2 laser tube
Laser-power	80W (100W 150w,or 180W for option)
Cooling Mode	Circulating-water-cooling
Power Adjustment	0-100% controlling, no segment and adjusting by software
Machine Control and Drive	Speedy DSP controlling, stepper motor
Max Engraving Speed	48000mm/min
Max Cutting Speed	500mm/min(when cutting 10mm thick of acrylic)
Repeating Location	0.01mm
Minimum Character	Chinese character 1.5mm, crisscross-row 1mm
Max Power	1800W
Adjustable Up-down Distance of Laser Head	40mm
Working Travel Area	1400x1000mm, 1450mm width with infinity material-feeding
Table Area	1450x1050mm
Up-down Range of Working Table	Mechanical 260mm
Working Voltage	AC220V 50Hz
Working Environment	Temperature: 0-45oC, Humidity: 5%-95%, and congeal-water removed
Controlling Software Language	English, Simplified Chinese, Traditional Chinese and procuring of multi-languages
Dictate Format	*.plt,*.dst,*.dxf,*.bmp,*.dwg,*.ai,*las, Support AutoCAD,CoreDraw direct outputting
Body Dimension (LxWxH)	2020x1480x1300mm
Packaging Dimension (LxWxH)	2120x1700x1450mm
Packaging	Wooden box
Gross Weight	487kg
Machine Color	Customizable
Delivery Time	15 days
Payment	T/T
Optional Equipment	Rotary attachment
	Motorized up-down table
	Water-cooling unit
	Red-light position
	Vacuum table
	DSP Off-line operation with usb flash

fabric laser cutting machine

- ce approval.
- thicker zinc fe alloy honeycomb working table and double-layer reinforced central platform, ensure large area cutting with high speed, stableness, precision, no scorched edge, just as small area cutting.
- particularly suitable for cutting garments fabric, plush toy fabric, car seat cushions, etc.
- single head or double head optional.

application

garments fabric, textile, cloth, toy fabric, leather, etc.
