automatic clicking press machine, 1.operate safely,long use life, 2.mould set easily, 3.low energy consumption - details see: https://www.machineto.com/jsaton-80-best-sales-large-scale-new-automatic-hydraulic-precise-four-column-clicking-press-cutting-machine-produced-in-china-10265578

jsaton-80,best sales large scale new automatic hydraulic precise four-column clicking press cutting machine(produced in china)

automatic clicking press machine use and character:

1.The machine is applicable for whole-broken or semi-broken operation of various nonmetal slices materials by die cutter. For example: such industries as plastics packing, pearl cotton packaging, rubber and printing etc.

2. Microcomputer controlled(MITSUBISHI orSIEMENS PLC), with simple ,prompt and accurate operation.

3.The main machine adopts double oil cylinder, double-crank connecting rod balancing, four-column precise guiding mechanism, which an guarantee that the cutting depth at every cutting position is same. 4. The pressing board carries out slow cutting when it presses downward to contact the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.

5. The central oil supply automatic lubricating system guarantees the service life and precision of machine.

6.Single-side or double-side automatic feeding system can be allocated to enhance the production efficiency of machine twice or thrice.

7. Cutting board micro-movement device can be allocated to evenly consume the cutting board and save cost.

8. Die cutter pneumatic clamp device can be allocated to make the replacement of die cutter convenient and prompt.

9.Products of special specifications can be specially designed and manufactured according to customer requirements.

Optional: .single-side and double-side automatic feeding systems; .cutting board micro-movement device; .die cutter pneumatic clamp device.

Yancheng Atong CNC Machinery Co.,Ltd is the leading manufacturer specialized in designing and manufacturing different kinds of cutting machines and laminating machines with the experience of several years.We have the wide sales market overseas,such as Uited States,Europe,Iran,Russia,Indonesia,Bangladesh,India,etc.

Products have passed international quality certificate ISO9001 and European Union CE qualification.Customer Satisfaction is our service tenet, we warmly welcome your coming and visit.

automatic clicking press machine:

model	jsaton-30	jsaton-40	jsaton-50	jsaton-60	jsaton-80
max force	30T	40T	50T	60T	80T
size of work table	1600x510mm	1600x610mm	1600x810mm	1600x810mm	1600x810mm
seissor speed	0.21m/s	0.21m/s	0.18m/s	0.18m/s	0.18m/s
platen to table distance	50-160mm	50-190mm	50-230mm	50-230mm	50-200mm
motor power	2.2KW	3.0KW	4.0KW	4.0KW	5.5KW
machine dimension	2200x900x1460mm	2300x1300x1500mm	2300x1500x1600mm	2300x1500x1600mm	2500x1800x2000mm
weight	2000kg	2200kg	2500kg	2700kg	3000kg

Remark:All of cutting machines we supply are not include any hydraulic oil.
