JG-FG Pharmaceutical Machinery Fluid Bed Dryer/Pelletizing

A fluidized bed is a bed of solid particles with a stream of air passing upward through the particles at a rate great enough to set them in motion. As the air travels through the particle bed, the particles behave as boiled water. The active motion creates the potential for improved mixing and results an isothermal property. In a bubbling fluidized bed, no temperature gradient exists within the mass of the fluidized particles. Because the temperature and volume of the air can be precisely adjusted, the process achieves fast heat transfer

The parameter:

JG FG-B Series Fluid Bed Dryer(as reference)
Specification			Model
Specification		Denomination	15	30	60	120	200	300	500
Material Container	Volume	L	45	100	220	420	670	1000	1500
	Dimension	mm	550	700	1000	1200	1400	1600	1800
Capacity(top spary)		Kg/batch	15	15	60	120	200	300	500
Blower		Kw	3	5.5	11	18.5	22	30	45
Steam	Pressure	Mpa	0.4-0.6
	Steam flow	Kg/h	20	60	120	140	180	310	400
Compression air	Pressure	Mpa	0.6
	Steam flow	m3/min	0.6	0.6	0.9	0.9	1.1	1.1	1.5
Noise	db		less than 75db
Towner Dimension(mm)	A		1900	2100	2250	2650	2800	3500	4000
	B		1350	1800	2400	3200	3800	4200	4200
	C		380	420	480	500	520	600	680
	D		1100	1500	2120	2400	2640	2800	2920
	E		2800	3900	4100	4500	5200	6200	6900
	F		550	700	1000	1200	1400	1600	1800
