Industrial intermittent ball mill with ISO certificate for sale

the feature of ball mill, 1.stable operation, 2.best grinding efficiency, 3.fine grinding ball mill, 4.high capacity - details see: https://www.machineto.com/industrial-intermittent-ball-mill-with-iso-certificate-for-sale-10314824

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):28-45kw
Capacity(t/h):2.5	Place of Origin:Henan China (Mainland)	Brand Name:Lanji	Model Number:TCQ2200*2400
Dimension(LWH):4.51.61.5m	Weight:8.2t	Certification:ISO9001	Warranty:1 year
After-sales Service Provided:Overseas service center available	Color:As per required	Max capacity:10t/h	Quality:Superior
Price:Competive	Business type:Manufacturer

Intermittent ball mill:

This machine works in both dry and wet methods intermittently, to mill, mix and discharge materials such as feldspar, quartz and clay. The slurry can pass through 1000 sieve pore. It's a kind of super fine grinding mill, so the feed material could be in medium size to get best grinding efficiency and economic profit.

Intermittent ball mill working principle:

The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Intermittent ball mill structure:

The machine is composed by feeding part, discharging part, turning part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The turning gearwheel adopts casting hobbing process and the drum is equipped with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable working condition.

Intermittent ball mill technical data :

Model	Capacity(t/h)	rotation speed(r/min)	Power(kw)	Weight(t)
TCQ910×1120	0.2	36	5.5-11	3
TCQ1200×1400	0.5	32	11-18.5	3.8
TCQ1500×1800	1	28	15-22	4.5
TCQ1800×2100	1.5	26	18.5-30	6
TCQ2100×2100	2.5	22	22-37	7.4
TCQ2200×2400	3	20	28-45	8.2
TCQ2500×2900	5	16	37-55	9.3
TCQ2800×3700	8	14.5	55-75	12.5
