Hyundai/China engine fork lift
Condition:New | Place of Origin:Beijing China (Mainland) | Brand Name:HYUNDAI | Model Number:HC25E07 |
Type:diesel engine forklift | Power Souce:Diesel Engine | Rated Loading Capacity:2500kg | Max. Lifting Height:3000mm |
Min. Lifting Height:2040mm | Fork Length:1070mm | Fork Width:122mm | Overall Dimensions:3652*1200*2140mm |
Certification:ISO | After-sales Service Provided:Engineers available to service machinery overseas | name:fork lift | emission standard:Europe 2 |
engine:HYUNDAI AG44/AG45 | oil consumption:lower and save | view operation:wide visible range | instument panel:agile and accurate |
equip:double suspension system | transmission:mechanical | mast:imported from South Korea | Weight:3780kg |
HCHD series hydraulic fork lift internal combustion forklift, in accordance with core technology of S.Korea hyundai corporation of heavy industry,
1.apparence:apparence is streamlined fitting wordly trend, brief and sprightly, dignified and generous, small turning radius.
2.safety operation: wide visual field, broaden the horizon of operator, fast and safety operate, safety valve installed on the elevating system, when the hydraulic hose broken, prevent the fork from falling suddenly, ensure safety production; locking valve installed on tilting system, the tilting cylinder self locking to prevent mast from forward and backward, enhance security of working performance; the flow control valve prevent the elevating cylinder from dropping fast under loading.
3.engine:hyundai AG45 engine, low emission and eddy type conbustion room, optimized orchestrate and advanced fuel oil system, have excellent low temperature motion performance, , low noise, high reliable, compact structure, steady dynamic transport, motive power transfer steady, increase engine machine oil cooling system.
4.heat dissipation: special increasing water tank, the radiating area and the tank capacity is 1.25 times bigger than like products,
HC20/25/30/35E(07)HD20/25/20/35E(07)
diesel fork lift , gasoline forklift truck, lift truk, fork lift
Balance weight diesel fork lift trucks, Hyundai engine
Europe 2 emission standard
feature | model | HC25E | HC35E/HD35E(07) | |||||||
Rated load capacity | kg | 2500 | 3500 | |||||||
Load center | mm | 500 | 500 | |||||||
size | STD MAST 2 stage | Fork max. lift height | mm | 3000 | 3000 | |||||
Fork size | T*W*L | mm | 40*122*1070 | 50*125*1070 | ||||||
Fork distance | MIN.*MAX. | mm | 240*1100 | 260*1100 | ||||||
Mast tilt angle | F/R | deg | 6°/12° | 6°/12° | ||||||
Outside size | Total length | mm | 3652 | 3870 | ||||||
width | mm | 1200 | 1280 | |||||||
Mast lowest height | mm | 2040 | 2087 | |||||||
Overhead guard height | mm | 2140 | 2170 | |||||||
Turning radius | Min outside | mm | 2280 | 2450 | ||||||
Min. right angle aisle width | mm | 2000 | 2300 | |||||||
performance | speed | Travel speed(unload) | mm | 19.5 | 19 | |||||
Lifting (load) | mm | 480 | 480 | |||||||
Max.gradeability | Speed 1.6km/h() | % | 25 | 20 | ||||||
weight | unloaded | Kg | 3780 | 4650 | ||||||
frame | Tires,2/2 | front | 7.00-12-12PR | 28*9-15-14PR | ||||||
rear | 6-9-10PR | 6.5-10-10PR | ||||||||
wheelbase | distance | mm | 1625 | 1750 | ||||||
Wheel tread | front | mm | 960 | 1000 | ||||||
rear | mm | 980 | 980 | |||||||
Ground clearance | At the lowest point | mm | 120 | 120 | ||||||
brake | Driving brake | Foot step | Foot step | |||||||
Stop brake | Hand brake | Hand brake | ||||||||
drive | battery | Voltage/capacity | v/Ah | 12-70 | 12-70 | |||||
engine | model | HYUNDAI AG44 | HYUNDAI AG45 | |||||||
Rated output | Kw/rpm | 47/2400 | 57/2500 | |||||||
Max. engine torque | Kg.m/rpm | 13.7/1600 | 15.7/1700 | |||||||
Strok/ Cylinder/displacement | L | 4/4/2.607 | 4/4/2.607 | |||||||
Gear box | type | Mechanical; | Mechanical; hydraulic | |||||||
Front/back shift | 2/2 | 2/2; 1/1 | ||||||||
Packaging Detail:seaworthy packing, packed in 20ft container. |
Delivery Detail:15-30days |
