Hydraulic small hay baler machine
Hydraulic small hay baler machine, 1) CE aprroved, 2) For bailing sawdust,hay,rice husk..loose material, 3) High efficiency - details see: https://www.machineto.com/hydraulic-small-hay-baler-machine-10060319
Condition:New | Automatic Grade:Automatic | Usage:Food Forming Machine | Place of Origin:Jiangsu China (Mainland) |
Brand Name:Huicheng | Model Number:HB110-10070 | Voltage:380V/50Hz | Power(W):15KW/20HP |
Dimension(L*W*H):3920*2880*1700mm | Weight:2700 kg | Certification:ISO9001-2000 system of quality certification | Nominal Force:50/60 ton |
packing size:750*430*310mm | packing maerial:saw dust, wood shavings, rice husk | capacity:2.5-3T/h |
Hydraulic small hay baler machine
The machine uses PLC control system, hydraulic transmission, horizontal level bagged, out of the bag speed, high output. The machine features simple operation, easy to use, a high degree of automation, less labor, the use of artificial feeding or conveyor automatic feeding all can. The machine is mainly suitable for wood chips, rice hull, the cotton seed shell, peanut shell pieces such as compression, compression sack a complete, convenient storage and lower transportation costs. The compression objects, easy to remove loose, use at environmental protection building materials, farmland fertilizer, and fungus mushroom cultivation and utilization.
Technical data
Model | Hydraulic power | Packing size | Feed opening size | Packing materials | Capacity | Voltage | power | Machine size | weight | Bag size |
HB90-10070 | 40/50Ton | 750*430*310mm | 1000*700mm | Hay mineral wool | 1.5-1.8T/h | 380V/50Hz | 11KW/15HP | 3920*2880*1700mm | 2400Kg | 760*1150mm |
HB110-10070 | 50/60Ton | 750*430*310mm | 1000*700mm | cotton seed,corn cob | 2-2.5T/h | 380V/50Hz | 15KW/20HP | 3920*2880*1700mm | 2700Kg | 760*1150mm |
HB140-10070 | 60/80Ton | 750*430*310mm | 1000*700mm | saw dust,wood shavings,rice husk | 2.5-3T/h | 380V/50Hz | 18.5KW/25HP | 3920*2880*1700mm | 3200Kg | 760*1150mm |
HB180-12070 | 80/100Ton | 750*430*310mm | 1200*700mm | saw dust,wood shavings,rice husk | 2.5-3T/h | 380V/50Hz | 22KW/30HP | 4250*3100*1700mm | 4300Kg | 760*1150mm |
Packaging Detail:Wooden packing/bare back packing |
Delivery Detail:20days |
