1)Cotton Waste Recycling Machine, 2)output:120kg/hr, 3)loose fiber,remove dust, 4)make use of waste resource, 5)new degin - details see: https://www.machineto.com/hot-six-roller-cotton-waste-recycling-machine-model-gm-410-10279093

Six roller Cotton Waste Recycling Machine Model GM-410

Function & Feature for Four roller Cotton Waste Recycling Machine Model GM-410:

1. This machine makes use of the centrifugal force generated by high speed rotation of take-in roller clean out impurities from raw material, loosen fibers, and then press the fiber into big flakes.

2. This machine can also remove the dust in the raw material.

3. It can be used to process fabric waste, yarn waste with the help of opening machine .

4. Also can used to process droppings ,card fly ect ,many kinds of spinning waste ,ginning waste independently . 5. Finished products can be again used in oe spinning mills to make yarn, filling pillows ,producing nonwoven fabric, filling toys ,sofa ect.

5. It is the best way to reduce cost and make good use of resources.

Technical Data for Four roller Cotton Waste Recycling Machine Model GM-410:

1. Output: 100~ 120kg /h

2. Diameter of take-in roller: 250 mm

3. Rotating speed of take-in roller first 1900r/ min; Second the third 2000r/ m, and the fourth 2100r/min

4. Dust basket: diameter: 500mm mesh: 2mm

5. Motor: Y132S-4 5.5KW four sets

6. Take-in wire :1.09x75º×7 teeth/25.4mm

7. Outside dimension (LXWXH,mm) : 4500mm X 1720mm X 1160mm

Specification	GM250*1000	GM250*1500	GM350*1250	GM400*1000	GM400*1250	GM400*1500
Roller Dia	250mm	250mm	350mm	450mm	400mm	400mm
Output	50-60kg/hr	80-100kg/hr	120-150kg/hr	100-150kg/hr	150-180kg/hr	200-220kg/hr
Motor	17.5kw	17.5kw	19kw	19kw	21kw	21kw
Dimension(mm)	5390*1700*1150	5390*2300*1150	5550*1950*1200	5550*1700*1200	5550*1950*1200	5550*2300*1200
Note

Six roller Cotton Waste Recycling Machine Model GM-610
