Screed powered by petrol engine, provides uniform vibration over the entire blade length and enhances concrete compaction - details see: https://www.machineto.com/honda-engine-concrete-truss-screed-10119339

Vibratory Screed powered by petrol engine, provides uniform vibration over the entire blade length and enhances concrete compaction, makes it possible to level up to 4 times more concrete than the traditional method, and do it more accurately. Only weight approximately 12kg, it's one of the lightest portable unit on the market.
Features :
1) Specially design, hardened aluminum blade ensuring a smoother finish than conventional screeds.
2) Heavy rubber mounts to reduce the vibration level on the handle.
3) Adjustable handle in height, vertical & horizontal position (optional)
4) The rounded ends of the blade make it easy to go around obstacles
5) The tilt-up stand keeps the engine out of concrete or off the ground obstacles.
6) One piece casting body easy connect to engine.
7)Emergency stop switch available.
8) 7 different working widths: 4ft/1. 2m, 6ft/1. 8m, 8ft/2. 4m, 10ft/3. 0m, 12ft/3. 7m, 14ft/4. 5m, 16ft/4. 9m.
9)Easily changed blades.

Surface Finishing Screed
Model	SF2-H
Engine	Air-cooled.2-cycle
Engine Type	Honda GX35
Power : kw(hp)	1.1(1.5)
Weight: kg(lbs)	19.2(42.2)
Blade
Size:m(ft)	1.22(4)	1.8(6.0)	2.44(8.0)
Weight:kg(Ibs)	2.9(6.4)	4.36(9.6 )	5.81(12.8)
Size:m(ft)	3.66(12.0)	4.47(14)	4.88(16)
Weight:kg(Ibs)	8.72(19.2)	10.16(22.4)	11.61(25.6)
packing(cm)	Engine: 56*54*52 Screed: 251*23*30 Handle: 85*65*30
