High quality Xinguang ball mill

Ball Mill, 1.Mn linning,durable, 2.whole base support, easy to installation, 3.special design, asving energy about 30% - details see: https://www.machineto.com/high-quality-xinguang-ball-mill-10314705

Condition:New	Type:Ball Mill	Capacity(t/h):1-500t/h	Place of Origin:Henan China (Mainland)
Brand Name:XINGUANG	Model Number:All	Certificate:ISO9001:2000	Capacity:1t-70t/h
Colour:as request	Max feed size:25mm	Min discharg size:0.074mm	Power:saving energy
Linner:Steel, rubber or slicon	Grinding kind:dry or wet	Supply spare parts:for whole life	After sales service:for whole using

contact supplier for High quality Xinguang ball mill

Ball Millis a key equipment to grind all kinds of ores and other materials.which is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc.

Ball Millconsists of feed&discharge parts, rotary shell, transmission part and other major components.Hollow shaft is with steel parts, lining is removable. Rotary gear adopts casting hobbing, and the tube body is with resisting liner.

Export:As the Brand Name of our Mining Machine, our Ball Mill Have been imported to Vietnam,Malaysia,Indonesia,Turkmenistan,Ghana,Morocco and other countries for gold separation,Iron&Copper concentration.

Wet Milling, Ball Mill

(1) Newest structure
(2) Easy maintenance and operation

(3) Durable wearing parts
(4) Low operating cost
(5) Big and fine grinding ratio

Model	Drum rotary speed (r/min)	Feeding capacity (t)	feeding size (mm)	Discharging size (mm)	Output (t/h)	Power (kw)	Weight (t)
Φ900×2100	38	1.5	≤15	0.075-0.89	0.5-2	15	3.9
Φ900×3000	38	2.51	≤15	0.075-0.89	0.8-3.5	22	5.0
Φ1200×2800	32	4.0	≤20	0.074-0.4	1.0-5.0	30	9.5
Φ1200×3000	32	4.5	≤20	0.074-0.4	1.2-5.6	37	11.5
Φ1200×4500	30	5.5	≤20	0.074-0.4	1.5-6.0	55	13.6
Φ1500×4500	27	11	≤25	0.074-0.4	4-10	95	21
Φ1500×5700	27	12	≤25	0.074-0.4	4-13	110	23.5
Φ1830×3000	24	12	≤25	0.074-0.4	5-15	130	31
Φ1830×3600	24	13	≤25	0.074-0.4	5-16	130	32
Φ1830×4500	24	14	≤25	0.074-0.4	5-18	155	33.5
Φ1830×7000	24	21	≤25	0.074-0.4	6-20	210	36
Φ2100×3600	24	21	≤25	0.074-0.4	7-35	215	39.5
Φ2100×4500	24	26	≤25	0.074-0.4	8-42	245	43.5
Φ2200×3000	21	28	≤25	0.074-0.4	8-43	245	46
Φ2200×4800	21	35	≤25	0.074-0.4	9-45	285	48
Φ2400×3000	21	23	≤25	0.074-0.4	8-60	285	55
Φ2700×4500	21	48	≤25	0.074-0.4	12-83	475	79
