High Performance YGMX Series High Pressure Grinder Mill For Sale

High Pressure Ultrafine Grinder Advantage, 1Land-saving, 2The transmission is steady and reliable, 3Three-dimensional structure - details see: https://www.machineto.com/high-performance-ygmx-series-high-pressure-grinder-mill-for-sale-10314361

Condition:New	Type:Raymond Mill	Place of Origin:Shanghai China (Mainland)	Brand Name:Vipeak
Model Number:YGMX Series	Certification:ISO9001/CE/IQNET/GOST	Warranty:The whole using life	After-sales Service Provided:Engineers available to service machinery overseas
Product Name:High Performance YGMX Series High Pressure Grinder Mill For Sale	Price:Negotiable	Test&Installation:Under our engineer's guide	Layout design:providing
Wind Velocity:14000~60250	Max feeding size:≤35mm	Speed of Main Unit:66~103r/m	Wind Pressure:7000~9264
Fineness of the finished products:≤1250 mesh	Speed of impeller:110-1750

Brief Introduction:

YGMX series high pressure ultrafine grinder is new type grinding equipment which is the latest design of our R&D Department. This grinder is widely used in non-metal minerals industry, mainly for producing minerals powder with Moh’s hardness below 9.3, humidity 8% and non-flammable non-explosive minerals.

Characteristics of YGMX series high pressure ultrafine grinder:

1.Three-dimensional structure

2.Land-saving

3. The screen-passing rate can reach to 99%

4.The transmission is steady and reliable

5.The transmission device of mainframe adopts airtight gear case and zonal wheel.

6. Centralized control for the electric system, convenient to operate.

Technical parameters of YGMX series high pressure ultrafine grinder:

Model	YGMX130	YGMX160	YGMX190
Roller	φ410×210	φ440×270	φ460×280
Ring	φ1280×210	φ1600×270	φ1900×280
Max. feeding size(mm)	≤30	≤35	≤35
Speed of Main Mill (t/m)	103	82	66
Wind Velocity	14000	23500	60250
Wind Pressure	7000	7700	9264
Impeller Speed	170-1750	130-1350	110-1100
Fineness of the finished products	≤1250 mesh	≤1250 mesh	≤1250 mesh

Fineness of final product		YGMX130		YGMX160		YGMX190
Mesh	um	Kg/h	KWh/t	Kg/h	KWh/t	Kg/h	KWh/t
325	≤44	3500	25.3	6500	24.5	20000	22
425	≤36	2800	29.2	5200	29.1	16000	27
600	≤22	1500	51.2	3000	49.4	9500	40
800	≤15	1000	71.3	2100	66.2	6800	58
1000	≤13	700	96.2	1500	86.5	5000	78
1250	≤10	500	117	1000	109	3300	95
