Type Raymond mill, capacity:1.2-3.5t/h, realible structure and high efficient, QA/QC:ISO9001:2000, After sales:1 year warranty - details see: https://www.machineto.com/high-efficient-raymond-mill-machine-hot-sale-in-middle-east-10314214

Detailed Product Description

1.World-class technology mill with 2.5-6.5ton/h
2.5R4119 raymond mill with 75kw
3.output of mill:0.044-0.2mm
4.ISO9001:2000

Specifications:

Reliable working condition

Convenient to adjust the fineness

High efficiency
Stable working performance

Advanced technology
Easy fineness adjustment and high fineness
Clean, environmental protection

Wide size range of final product

Application of Raymond mill:

Raymond mill is suitable for grinding the nonflammable and non-explosive materials with humidity below 6% and Mohs hardness less than 7 such as barite calcite feldspar limestone marble glass and so on. It is widely used in mining chemical industry and building materials.

Features and benefits of Raymond mill:

1. The whole plant is a vertical structure of strong systematic characteristic, so it occupies small area. From crushing of raw material to grinding and packing is an independent production system.

2. Driving system of main frame adopts airtight gearing and pulley, drives smoothly and operates main parts of the whole plant are made from cast and steel of high quality. The techniques is so subtly that insures the durability of whole plant.

Working principle of Raymond mill:

Firstly, raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding. After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.

Technical parameter:

Model	Roller Number	Roller Size L×H (mm)	Ring Inner Diameter and Height (mm)	Max Feed Size (mm)	Fineness of product (mm)	Capacity(t/h)	Main frame power (KW)	Weight (t)	Overall Dimension (mm)
3R2115	3	210×150	630×150	15	0.044-0.2	0.4-1.6	15	3.6	4500×2800×5800
3R2615	3	260×150	780×150	20	0.044-0.2	0.8-2.5	18.5	4.2	5650×3305×5950
3R2715	3	270×150	830×150	20	0.044-0.2	0.9-2.8	22	4.8	5600×3400×5900
4R2715	4	270×150	830×150	20	0.044-0.2	1.1-3.0	22	5	5600×3400×5900
4R3016	4	300×160	880×160	20	0.044-0.2	1.2-3.5	30	8.5	6500×4100×5200
4R3216	4	320×160	970×160	25	0.044-0.2	1.8-4.5	37	1.5	9900×5800×10580
5R4119	5	410×190	1270×190	25	0.044-0.2	2.5-6.5	75	25	10500×6500×13530
Note:Above weights of 3R2115, 3R2615, 3R2715, 4R2715, 4R3016 are main famous but the weight of 4R3216 is that of a complete set of equipment.

If you need any other information, please feel free to contact me !
