High capacity Xinyuan Brand Raymond Grinder machine/ Raymong grinding machine/ Raymond mill

Raymond Grinder machine, 1)non-pollution,energy saving., 2)wide size range of final product., 3) broad-spectrum,lower noise - details see: https://www.machineto.com/high-capacity-xinyuan-brand-raymond-grinder-machine-raymong-grinding-machine-raymond-mill-10314370

Condition:New	Type:Raymond Mill	Motor Type:Other	Capacity(t/h):0.5-1.5
Place of Origin:Henan China (Mainland)	Brand Name:Xinyuan	Model Number:5R4119	Certification:ISO9001;2008
Warranty:1 year	After-sales Service Provided:Overseas third-party support available	color:as request	installtion:Support Techinical guidance

Raymond Grinder machine:

Raymond mill produced by our company is mainly used to grind non-inflammable and non-explosive materials with Moh’s hardness below 7 and moisture content below 6% such as barite, calcite, potash feldspar, talcum, marble, limestone, ceramic, glass, etc Raymond grinder can be used in mining, chemical industry, construction materials, metallurgy and so on. The final products can be adjusted freely from 100 mesh to 425 mesh.

Working Principle of Raymond grinder machine:
Firstly, raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.

Picture Showing of Raymond Grinder machine:

Contact with Tina Liang
