HC-DP-AD Automatic Adult Diaper Machine

Automatic Adult Diaper Machine:, 1.PLC,frequency convertor control, 2.Perfect after-sale service, 3.Competitive price - details see: https://www.machineto.com/hc-dp-ad-automatic-adult-diaper-machine-10325758

Place of Origin:Fujian China (Mainland)	Brand Name:HC-CREATE	Model Number:HC-DP-AD	After-sales Service Provided:Engineers available to service machinery overseas
speed:100-300pcs/min	power:380V/50Hz	install power:400kw	machine size:2443.3 m
compressed air:5000-7000nl/min	color:order by customer	train:one month train	system:computer control system
finished product:adult diaper	material:Non-woven and jumbo roll paper

contact supplier for HC-DP-AD Automatic Adult Diaper Machine

Specifications

1.1 set crusher ,the amount of pulp is setted by the frequency convertor.
2.Pulp core use the high-pressured wind adsorption, the single-channel wheel shaping, bottom and top choose the toilet paper as a foil.
3.SAP mix with pulp, the quantity can be adjusted by touch screen.
4.The pulp pattern are net type, which can be designed as order.
5.Add lead-flow N.W fabric blue core piece unit.
6.Protection-leakage unit. Heat-press type.
7.Left-right Side sticker are added on the machine, can adjust the space to match with the different width of L, M, S size.
8.The front waist unit, on-line glue coating. Elastic waistline unit.
9.Lycra elastic roll unit, sides of the pulp equipped 3 lycra. 2 sides of leakage-barrier products with two lycra.
10.Arc cutting unit, knife material is D2.
11.The product outer-cut take blow-cut manner.
12.The product vertical folds, compacted and shaped after cutting.
13.Product three-folded.
14.Main electricity machine frequency timing.

Automatic Adult Diaper Machine

Technical Parameters of Automatic Adult Diaper Machine
Item	Speciation
Model	HC-DP-AD
Designed production speed	100PCS/min
LED Specification	SMD3528(3-in-1)
Cell Board Dimension	320*160
Unit Board Rssolution(Length*Width)	32*16
Dot ensity (Dot/m²⁾	1000
