Gypsum Mill for Grinding Gypsum, 1. 40-325 mesh gypsum powder, 2. Large capacity, 3. High manganese steel - details see: https://www.machineto.com/gypsum-mill-for-grinding-gypsum-10314518

Gypsum Mill For Grinding Gypsum

1) Application of gypsum mill:

High Pressure Suspension Mill is a new kind of mill, which starts an epoch of high efficiency and low cost in international mining industry. High Pressure Pendulum Mill can be used to grind non-inflammable and non-explosive materials with Moh’s hardness below 9.3 and moisture content below 6%, such as bentonite, barite, limestone, pottery, scoria,etc.

2). Detailed Photos of Gypsum Mill:

Gypsum Mill For Grinding Gypsum

3) Advantages of gypsum mill :

1. Compared with other mills, its capacity increases by 20%-30% under the same power condition, and compression force of rollers to material improve 800-1200 kgf under the force of high-pressure spring.
2. Size of final product can be 30–425 mesh. Some can reach the fineness of 1000 mesh.
3. Meets the requirement of national dust-dump standard.
4. The separator can be adjusted very easily.
5. The multi-class seals are adopted to keep the grinding equipment tightly closed.

4) Working Principle of Gypsum Mill:
Firstly, raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing. The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipes as the final products.

Gypsum Mill For Grinding Gypsum

5) specifications of gypsum mill:

Model	Piece of roller	Size of the roller (mm)	Feed size (mm)	Fineness of powder (mm)	Capacity (t/h)	Motor power (kW)	Fan Power (kw)	Dimension (MM) (L*W*H)
QMB6515	3	210*150	12-20	0. 613-0. 033	0.25-2	15	11	4100*3300*4500
QMB7815	3	260*150	15-20	0. 025-0. 005	0.28-3	18.5	15	4300*3500*5100
QMB8314	3	270*150	15-20	0. 025-0. 005	0.35-3.4	22	18.5	5300*4100*5200
QMB3016	3	300*150	15-20	0. 025-0. 005	0.35-4	22	18.5	5300*4100*5200
QMB9517	4	310*150	15-25	0. 025-0. 005	1.5-9	37	30	7100*5900*7900
QMB4121	5	410*210	15-25	0.613-0.044	4-8	75	55	7850*8000*9700
QMB4528	6	450*280	15-35	0.613-0.044	5-22	132	132	12550*5700*8300

Work Flow: Gypsum Rock --> Jaw Crusher --> Bucket Elevator --> Hopper --> Vibrating Feeder -->Gypsum Mill -->Screw Conveyor --> Bucket Elevator --> Silo --> Trucks or Bags.

7)Spare Parts of Gypsum Mill:
