Mortar Spraying Machine:

Overall Description:

This series of spraying machines are new energy-saving,environmentally friendly construction machinery, researched and improved based on German advanced technology and considering the characteristics of construction and building materials. This new machine is pretty suitable for every type of plaster spraying construction and engineering.

Operation Instructions

The GLP-2B mortar spraying pump is a spraying unit with high reliable, well-adapted, sturdy and durable, easy operated. Only three peopled are needed for the construction, one conveys the raw materials, one controls the spraying gun, and the third one for assistant work (ex. move the tube). Compared the traditional manual construction, it can save the labor, money and time. Additional, the project quality is much better than manual construction. The spraying pump equipped with safety operating control system, and it would stop no matter which parts have fault, which can guarantee the safety of the machine as well as the operator.

Application Scope

Normal mortar, thermal insulation mortar, dry mortar, anti-crack mortar, interface agent, lacquer putty, building glue, adhesive, fireproof materials, epoxy coatings.
Construction Projects
Interface agent, wall mortar spraying, grid structure spraying, floor grouting, fireproof and anticorrosive paint, strong viscosity painting, etc.

Technical Parameters:

Working Capacity	2-4m/h	Max aggregate diameter	4mm
Max Pressure	3MPa	Pipeline inner diameter	25/32mm
Horizontal Delivery distance	50m	Hopper Capacity	30L
Vertical Delivery Distance	30m	Loading Height	800mm
Power	4kw	Dimension	1465×700×1150mm
Voltage	380v/220v
Hose Diameter	13mm	Air Compressor	400L/min;8bar,3kw
Max RPM	200-600	Weight	200kg

Pictures for your reference:

....
