forged mill ball, -High-efficiency, -Energy saving ,Big capacity, -High quality ISO9001-2008,, -Professinal - details see: https://www.machineto.com/forged-mill-ball-for-energy-saving-ball-mill-10314774

Forged mill ball

Brief introduction of ore ball mill:

The Cement ball mill is widely used to grind various medium-hard ores and other materials in mining, building materials, chemical industries, etc. The ball millcan be divided into dry type and wet type according to the milling method; grid type and overflow type or center-discharge and side-discharge type according to the ways of discharge; bearing-mill and bearing pad mill according to the different methods of supporting; rim drive and center drive according to the different ways of transmission. The large mill with diameter above 3 meters is especially configured with jack-up devices for easy maintenance; the dynamical pressure bearing and the static pressure bearing can operate stably. Slow rotation is convenient for overhaul and start; the oil sprayer lubrication device can make big and small gears reliable. The main motor of large mill is high pressure asynchronous motor or synchronous motor, which should be notified in the orders

Lab ore ball mill:

1) is an efficient tool for grinding many materials into fine powder.
2) widely used in building material, and chemical industry.
3) can be used b oth dry and wet.

4) As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.
5) The longer the ceramic mill runs, the finer the powder will be.
6) Our rod mill have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, powder various chemicals.

Structure of ore ball mill:

The machine is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The rotation big gearwheel is made by cast hobbling processing and the drum is equipped with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable working condition. Moreover, according to different materials and discharging methods, there are dry ball mills and wet ball mills for choice.

Working Principle:

The ball millis a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of ceramic ball in the chamber. The centrifugal force caused by rotation of barrel brings the ceramic ball to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Ball mill specification:

Model	Speed of Barrel (r/min)	Weight of Ball (t)	Feeder Opening Size (mm)	Discharge Opening Size(mm)	Capacity (t/h)	Motor Power (kW)	Weight (t)
MQYG900×1800	36	1.5	≤20	0.075-0.89	0.65-2	18.5	3.6
MQYG900×3000	36	2.7	≤20	0.075-0.89	1.1-3.5	22	4.6
MQYG1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	45	12.5
MQYG2200×6500	22	30	≤25	0.075-0.4	14-26	280	52.8
MQYG2200×7500	22	33	≤25	0.075-0.4	16-29	380	56
MQYG2200×9500	22	38	≤25	0.074-0.4	18-35	475	62
MQYG2400x4000	22	28	≤25	0.075-0.4	95	210	73
MQYG2400x6500	22	36	≤25	0.075-0.4	7-110	260	89.26
MQYG2400x7000	21	57	≤25	0.075-0.4	13-150	680	97.69
MQYG2700x4500	21	36.7	≤25	0.074-0.4	13-150	450	91.57

Ball mill prices are reasonable in Zhengzhou Hengrui. We serve our customer wholeheartedly. We hope to build business relationship with you in the long run

Final Produt from ball mill

We have various ceramic balls for ball mills, you are welcomed to visit our factory and we can talk more and understnd your need more clearly, thank you. Tel: 15936202574
