this machine is a new type carding machine for artificial fur and so on furs ,fit for chemical fibers with length 25-127mm. - details see: https://www.machineto.com/fn271f-high-speed-wool-carding-machine-10279013

Application:

This machine is mainly used to open,card and mix the chemical fibers and blendings,condense them into wool tops of certain specification s and then coil them into sliver can regularly for the next process.

The applicable materials :chemical fibers and its synthetic fibers with the length 25-127mm,the dtex:0.8-30D.Chemical fibers including the polyester fibers,acrylon fibers and polypropylene fibers and so on.

Main features:

1.With the metallic detecting device to prevent the machine jams and protect the machine's safety.

2.The over-low speed stop motion to prevent the machine jams.

3.With the suction system to reduce the cleaning efficiency.

4.Autoleveller system guarantee the evenness and stability of wool tops.

5.With 3-working position or 4-working position auto can changer to further lessen the labor intensity.

6.The touch display screen making the operation more easier and increasing the working space.

7.With the MAN-machine CONVERSATION to control the inverter making the frequency more stable and ensuring the normal running of machine.

machine width	1200,1500cm	applicable material	chemical fiber and its blendings
feeding form	automatic continous feeding	delivery speed	200m/min
delivery tops weight	7-20g/m	total draft multiple	32-140
Max.production	240kg/h	cylinder working dia.	770mm
cylinder speed	400r/min	licker-in working dia.	250mm
licker-in speed	600r/min	doffer working dia.	650mm
doffer speed	10-75r/min	machine weight	11000kg
floor space	11000*2290/11000*2590	total power	12kw
sliver can specification	600mm*900mm,400mm*1100mm	suction	2200m3/h per set
coiler type:	3-position or 4-position automatic can changer

the electrical control box is located inside the framework of the machine front part and the touch display screen is fixed on the left encloser of the machine front part,so it is convinient to operate .The touch screen can be used to display all functions and faults and set the relative technological parameters.

The autoleveller system can guarantee the evenness and stability of delivery tops by testing the input layer weight and controlling the feeding speed through the computer.
