FL Fluid belt dryer

OurFL Fluid belt dryeris suitable for tablet, capsule, low sugar or sugar granule of Chinese medicine.

1. The flow ability is improved and the dust is reduced.
2. The operation is safe.
3. No need corner. Therefore the loading and unloading are quick, light and clean
4. It's safe for operator because the anti static filtering cloth is adapted.
5. The operating personnel can not be damaged if explosion take place because there is releasing holes.
6. It meets the requirements of GMP.

Technical Parameters:

Item		Unit	Spec
			3	5	15	30	60	120	200	300	500	1000
vessel	volume	L	12	22	45	100	220	420	670	1000	1500	3000
	diameter	mm	300	400	550	700	1000	1200	1400	1600	1800	2200
capability	min	kg	1.5	4	10	15	30	80	100	150	250	800
	max		4.5	6	20	45	90	160	300	450	750	1200
fan	velocity	m3/h	1000	1200	1400	1800	3000	4500	6000	7000	8000	13670
	pressure	mmH2O	375		480		950					1400
	power	kw	3	4	5.5	7.5	11	18.5	30	37	45	90
steam consumption		kg/h	15	23	42	70	141	211	282	366	451	750
compressed air expenditure		m3/min	0.9				1.0		1.1	1.5	3.0	4.0
weight of the main body		kg	500	700	900	1000	1100	1300	1500	1800	2500	3500
steam pressure		MPA	0.1-0.4
temperature			Adjustable at the range from room temperature to 120
working time		min	45-90 decided in accordance with the properties of raw materials
collect rate		%	≥99
noise		dB(A)	≤75dB (A) during installation, main machine is separated from fan.
size (L×W×H)		m	1.0×0.6 ×2.1	1.2×0.7×2.3	1.25×0.9 ×2.5	1.6×1.1×2.5	1.85 ×1.4×3	2.2×1.65×3.3	2.34×1.7 ×3.8	2.8×2.0×4.5	3×2.25×5.0	4×2.8×7.2

Nouya Machinery Companyis one famous group and apply itself to R&D,manufacture machinery for Pharmaceutical,Chenical,food and so etc fields.

OurMain Productsare: Tablet press,Mixer,Crusher,Granulator,Dryer,Coater,Packing machine,Filling Machine,Miller and Pulverizer, Feeder,Oven, Deduster, Dust Collector, vibration sieves...

We also supply punch die sets and spare parts in standard or not.
