Flat-Bending Glass Tempering Furnace

Technical Specification

The performance of the product described in the following text conforms to that made of the high-quality float glass specified by national standards in GB11614—1999Float Glass.

Note: (1) The 3.2mm thickness of glass should be ≥3mm

(2) Four-side edges of the glass should be ground by diamond wheel until being beveled. No hole or chamfers are allowed.

The productivity may be reduced by 10-30% in the following cases

1. When the length of an individual piece of glass exceeds 3050mm
2. For low-E glass
3. For glasses of other special size, processing requirement or performance.
4. Yield Rate: 97% (for high-quality float flat glass specified by GB11614—1999, with four-side edges ground, and no holes nor chamfers)
5. Glass Varieties to be Produced: Ordinary glass, pattern glass, reflective glass, color glazed glass and coated Low-E (Radiance Value: e≥0.1) glass
6. Product Quality Standards

Technical Specification

The Flat Glass			The Band Glass
Max.	Min.	Glass Thickness	Max.	Min.	Glass Thickness	Glass Curvature Radius
2440×4200 mm	120×250 mm	5.0-19.0 mm	2500×1000 mm	200×350 mm	5.0-15.0 mm	R≥450

The Samples

The Part Of Eqiupment
