FD20 Isuzu Engine 2 Ton Side Shifter Diesel Forklift Truck With CE Certification
1. With isuzuC240 Diesel engine, 2. Xinchang 490Diesel engine is available, 3. Capacity 2Ton diesel forklift, 4. Passed CE - details see: https://www.machineto.com/fd20-isuzu-engine-2-ton-side-shifter-diesel-forklift-truck-with-ce-certification-10110123
Condition:New | Place of Origin:Guangdong China (Mainland) | Brand Name:Verace | Model Number:FD20 |
Type:Diesel foklift | Power Souce:Diesel Engine | Rated Loading Capacity:2000kg | Max. Lifting Height:3000mm |
Min. Lifting Height:110mm | Fork Length:1070mm | Fork Width:122mm | Overall Dimensions:2570*1160*1990mm |
Certification:CE | After-sales Service Provided:No overseas service provided | Cap:2 Ton | Lifting height:3M-6M |
Weight:3350kg |
FD20 Isuzu Engine Verace Brand 2 Ton Diesel Forklift Truck
Engine choice:
- Engine 1: With Xinchang 490Diesel engine
- Engine 2: With isuzuC240 Diesel engine
- 3M 2Stage Duplex mast
- Chinese Seat
- Pneumatic Tire
- 1070MM Forks
Picture:
Parameter Name Power model | Unit | FD15 | FD18 | FD20 |
Diesel | Diesel | Diesel | ||
Rated capacity | kg | 1500 | 1800 | 2000 |
Load center | mm | 500 | 500 | 500 |
Lifting height | mm | 3000 | 3000 | 3000 |
Free lifting height | mm | 115 | 115 | 135 |
Size of forks (L*W*H) | mm | 920*100*35 | 920*100*40 | 1070*122*40 |
Mast tilt angle(Front/Back) | . | 6/12 | 6/12 | 6/12 |
Minimum turning radius | mm | 2060 | 2060 | 2240 |
Minimum right-angle stacking aisle width | mm | 3680 | 3680 | 4110 |
Minimum right-angle aisle width | mm | 1865 | 1865 | 2010 |
Minimum ground clearance | mm | 105 | 105 | 110 |
Overhead guard height | mm | 2040 | 2040 | 2070 |
Front overhang | mm | 400 | 400 | 470 |
Max driving speed (Full load) | km/h | 14.5 | 14.5 | 19 |
Max lifting speed (Full load/Without load) | km/h | 460/500 | 460/510 | 490/510 |
Max tractive force (Full load) | KN | 16 | 16 | 17 |
Max grade ability | % | 20 | 20 | 20 |
Overall length( No forks) | mm | 2250 | 2250 | 2570 |
Overall width | mm | 1086 | 1086 | 1160 |
Max fork lifting height(With load backrest) | mm | 3860 | 3860 | 4024 |
Mast height | mm | 1955 | 1955 | 1990 |
Tyre Front wheel | mm | 6.50-10-10PR | 6.50-10-10PR | 7.00-12-12PR |
Tyre Back wheel | mm | 5.00-8-10PR | 5.00-8-10PR | 6.00-9-10PR |
Axle base | mm | 1400 | 1400 | 1600 |
Wheel base(Front/Back) | mm | 890/920 | 890/920 | 970/970 |
Dead weight(No load) | kg | 2680 | 2890 | 3350 |
Voltage/Capacity | V/Ah | 12/90 | 12/90 | 12/90 |
Model | XINGCHANG485BPG | XINGCHANG485BPG | XINGCHANG490BPG | |
Rated power | kw/r.p.m | 30/2600 | 30/2600 | 37/2650 |
Rated torque | Nm/r.p.m | 131/1800 | 131/1800 | 148/2000 |
Cylinders diameter *Stroke | mm | 0.9 | 85*100 | 9*100 |
Number of cylinders | 4.0 | 4.0 | 4.0 | |
displacement | L | 2.27 | 2.27 | 2.54 |
Fuel tank capacity | L | 45 | 45 | 60 |
Transmission Gear position Front/Back | 2/2 Manual shift 1/1 Power shfit | 2/2 Manual shift 1/1 Power shfit | ||
Working pressure | Mpa | 14.5 | 17.5 |
Packaging Detail:Standard exporting package |
Delivery Detail:15 days-30 days |
