Farm stainless steel 304 milk cooling storage insulation tank hot sell

Best Farm stainless steel 304 milk cooling storage insulation tank hot sell for 2 times milking direct cooling type.Long service - details see: https://www.machineto.com/farm-stainless-steel-304-milk-cooling-storage-insulation-tank-hot-sell-10025876

Processing:Heat Exchanger,tig	Condition:New	Place of Origin:Henan China (Mainland)	Brand Name:LEO
Model Number:LEO-RCL	Processing Types:Milk	Voltage:380v	Power(W):7kw
Weight:640kg	Dimension(LWH):5200x1900x1800	Certification:iso57082b	Warranty:3 years
After-sales Service Provided:Engineers available to service machinery overseas	Material:S.S304	Electricity:380V-460V 50hz

Our Stainless steel fresh Milk fast cooling tank detail:

<1>Cooling speed :meet ISO5708 2BΙΙ

<2>Compressor:Copeland-compliant scroll compressor.
<3>tank body:SUS304, One time pressing seam of end.radii of arc ≥30mm.

<4>Compressor and tank body can be separated installed.

<5>Insulation layer:60-80mm.temperature rise less than 2 celsius within 24 hours.

<6>evaporator:dimple jacket which.has longer life .ususlly 2 or 3 times longer than nomal one.

<7>electrical control box:water resistant,electric shock proof, wrong manipulation proof

<8>optional unit:

1.Auto-washer system:You can set different washing programs like Cold water,hot water,warm water rinse,also alkaline or acid recirculation and it will auto carry out you programs on time.

2.Electronic computation system to measure milk weight precision 0.001.data can be print out with printer.

3. Heat recovery system with function of provide hot water without energy consumpation.

Item

RZLG03-1

RZLG03-2

RZLG03-3

RZLG03-4

RZLG03-5

RZLG03-6

RZLG03-8

RZLG03-10

Capacity L

1050

2100

3200

4100

5200

6200

8200

10200

Dimension

Mtrs

Integrated

Auto-washer1

---

Closed type

Openable type

4.07×1.8×1.6

4.07×1.86×1.8

4.27×2.03×1.93

4.27×2.14×2.06

4.92×2.2×2.16

5.77×2.2×2.17

3.22×1.8×1.60

Auto-washer2

---

3.15×1.8×1.60

---

3.9×1.8×1.6

3.9×1.86×1.8

4.1×2.03×1.93

4.1×2.14×2.06

4.75×2.2×2.16

5.6×2.2×2.17

Pump-washer

2.55×1.44×1.42

3.05×1.8×1.60

3.45×1.44×1.1

3.8×1.8×1.6

3.8×1.86×1.8

4×2.03×1.93

4×2.14×2.06

4.65×2.2×2.16

5.5×2.2×2.17

Segregated

Auto-washer1

---

2.07×1.8×1.60

---

2.92×1.8×1.6

2.92×1.86×1.8

3.12×2.03×1.93

3.12×2.14×2.06

3.77×2.2×2.16

4.62×2.2×2.17

Auto-washer2

---

2×1.8×1.60

---

2.75×1.8×1.6

2.75×1.86×1.8

2.95×2.03×1.93

2.95×2.14×2.06

3.6×2.2×2.16

4.45×2.2×2.17

Pump-washer

---

1.9×1.8×1.60

2.45×1.44×1.1

2.65×1.8×1.6

2.65×1.86×1.8

2.85×2.03×1.93

2.85×2.14×2.06

3.5×2.2×2.16

4.35×2.2×2.17

Compressor(Copeland)

ZB21

ZB38

ZB45

ZB38×2

ZB45×2

ZB48,ZB58

ZB76,ZB48

1.04×0.8×0.67

1. 22×0.8×0.77

1. 22×0.8×0.77*2

1. 22×0.80×0.9*2

1. 22×0.81×1.07*2

Refrigerating capacity W

11400

14600

17600

14600×2

17600×2

19700+23000

30800+19700

Agitator motor KW

0.09

0.25

0.37

0.37×2

Milk pump KW

1.5

2.2

Condensing fan KW

0.3×2

0.3×4

Compressor power KW

2.68

4.43

5.27

4.43×2

5.27×2

5.83+6.89

9.13+5.83

Total power KW

4.87

6.78

7.74

11.93

13.61

16.86

19.1

Agitator moter RPM

Milk outlet

Dg51

Milk inlet

Dg38

Cleaning joint

Dg38

refrigerant

R404A

Power supply

3-380V 50HZ

Control box wire diameter(Anti-water)

3×2.5+1×1.5

3×4+1×2.5

3×6+1×4

3×10+1×6

Milk pump wire diameter(Anti-water)

3×1.5+1×1

Main power wire diameter

3×2.5+1×1.5

3×4+1×2.5

3×6+1×4

3×10+1×6

Xinxiang Leo Machinery Co., Ltd. is one of the biggest dairy machinery manufacturers which was reformed from the former military industrial enterprise in 2002. We now have over 600 staff members and fixed assets of more than RMB80,000,000, covering an area of 250,000 squremeters.

Now we have become the biggest manufacture base of China of milk cooling tanks (bulk milk coolers/direct expansion milk coolers), road milk tanks, milk tank trailers, milk transport tanks, transportation warmth keeping tanks, milking machines, trolley milking machines, liquid nitrogen tanks, vibratory separators, feedstuff mixing and blending vehicles and aseptic fillers.

We've provided more than 10,000 sets of equipment within twenty years. Based on advanced technology, modern equipment, strict production control, we succeed in supplying most national reputed clients like YILI, MENGNIU, SHENGYUAN, SANYUAN, RED STAR, ROBUST, JUER and NESTLE. They are all loyalty clients of us. LEO also provides OEM and becomes the symbol of high-quality and heavy-duty machineries.

Choose true suppliers, please contact us. LEO will be your loyal partner!
