factory with ISO copper ore, gold ore wet ball mill

gold ore ball mill, 1.ISO approved, 2.provide free test in factory, 3.Energy-saving ball mill, 4.20 years experience - details see: https://www.machineto.com/factory-with-iso-copper-ore-gold-ore-wet-ball-mill-10313918

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):According to type
Capacity(t/h):1-50 ton/hour	Place of Origin:Henan China (Mainland)	Brand Name:HC	Model Number:HC
Dimension(LWH):According to type	Weight:According to type	Certification:ISO9001	Warranty:12 months,1year(wearing parts excluded)
After-sales Service Provided:Engineers available to service machinery overseas	installation:under our engineer guide	certificate:ISO 9001:2008	after-sale service:for whole using life
pre-service:free	output size:0.0075-0.3mm	feed size:0-25mm	color:as your require
spare parts supply:whole working life with good prices	test machine:we will test the machine before delivery

general introduction factory with ISO copper ore, gold ore wet ball mill

factory with ISO copper ore, gold ore wet ball mill is a a kind of grinding machine used to mill the crushed materials into extremely fine power, this series ball mill not only used in copper ore,gold ore ,but also applied for industrial and mining enterprise such as metallurgy, building materials, chemical and other grindable materials, wet ball mill can be used for open circuit grinding, also for the circle grinding with power feeder. the bal mill has many advantages ,for instance:ISO certificate,20 years experience, etc.

--------------------------------------------------------------------------------

features factory with ISO copper ore, gold ore wet ball mill

1.Strong to be ground;

2.Great ventilation;

3.Finesse of the products;

4. High output ball mill

5. Easy to operate with long performance life;

---------------------------------------------------------------------------------

Working principle factory with ISO copper ore, gold ore wet ball mill

factory with ISO copper ore, gold ore wet ball mill is horizontal cylindrical rotation device, driven by brim gearwheel. There are two chambers and grid. In the first chamber of cement ball mill, there are stage liners and ripple liners as well as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material,that is the first step of cement grinding. After the primary grinding, materials go into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball, and also like the first step process to grind materials.after the secondary grinding, material is discharged from the discharging of cement ball mill. finally the cement ball mill is finish his work.

-----------------------------------------------------------------------------------

the parameters of factory with ISO copper ore, gold ore wet ball mill

model	Speed of bucket (r/min)	Weight of ball	Size of feed opening(mm)	size of outputting feed (mm)	Production (t/h)	Power (kw)	Weight (T)
900×1800	38	1.5	≤20	0.075-0.89	0.65-2	18.5	3.6
1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	45	12.5
1200×4500	32	7	≤25	0.074-0.4	1.6-5.8	55	13.8
1500×3000	27	8	≤25	0.074-0.4	2-5	90	17
1500×5700	27	15	≤25	0.074-0.4	3.5-6	132	24.7
1830×3000	24	11	≤25	0.074-0.4	4-10	180	28
1830×6400	24	23	≤25	0.074-0.4	6.5-15	210	34
1830×7000	24	25	≤25	0.074-0.4	7.5-17	245	36
2200×5500	21	30	≤25	0.074-0.4	10-22	370	48.5
2200×6500	21	30	≤25	0.074-0.4	14-26	380	52.8
2200×7500	21	33	≤25	0.074-0.4	16-29	475	56
